|$0
AXLE ASSEMBLY, REAR(SEE FIG. F4500-01A0)
SN: A81001-UP-UP
-1шт.
1
419-22-21230
YOKE
SN: A81001-UP-UP
1шт.
2
418-22-21310
PROTECTOR
SN: A81001-UP-UP
1шт.
|$3
419-22-21800
PINION ASSEMBLY, GEAR
SN: A81001-UP-UP
1шт.
3
NSS
PINION
SN: A81001-UP-UP
1шт.
4
NSS
PINION BEVEL
SN: A81001-UP-UP
1шт.
5
419-22-11810
BEARING
SN: A81001-UP-UP
1шт.
6
419-22-21631
CAGE
SN: A81001-UP-UP
1шт.
7
419-22-11820
BEARING
SN: A81001-UP-UP
1шт.
8
418-22-21330
SEAL, OIL
SN: A81001-UP-UP
1шт.
9
417-15-13770
HOLDER
SN: A81001-UP-UP
1шт.
10
01011-61615
BOLT
SN: A81001-UP-UP
1шт.
11
07000-13042
O-RING
SN: A81001-UP-UP
1шт.
12
07000-15180
O-RING
SN: A81001-UP-UP
1шт.
13
417-22-11360
SHIM - 0.002 IN. (0.05 MM)
SN: A81001-UP-UP
2шт.
|$15
417-22-11370
SHIM - 0.008 IN. (0.20 MM)
SN: A81001-UP-UP
2шт.
|$16
417-22-11380
SHIM - 0.012 IN. (0.30 MM)
SN: A81001-UP-UP
2шт.
|$17
417-22-11390
SHIM - 0.031 IN. (0.80 MM)
SN: A81001-UP-UP
1шт.
14
01010-61235
BOLT
SN: A81001-UP-UP
1шт.
15
01643-31232
WASHER
SN: A81001-UP-UP
10шт.
|$20
417-22-27100
DIFFERENTIAL ASSEMBLY, LIMITED SLIP
SN: A81001-UP-UP
1шт.
16
417-22-27110
CASE
SN: A81001-UP-UP
1шт.
17
417-22-27190
COVER
SN: A81001-UP-UP
1шт.
18
417-22-27210
RING, PRESSURE
SN: A81001-UP-UP
2шт.
19
417-22-27220
SHAFT
SN: A81001-UP-UP
1шт.
20
417-22-27310
PINION
SN: A81001-UP-UP
4шт.
21
417-22-27320
GEAR
SN: A81001-UP-UP
2шт.
22
417-22-27370
WASHER, T2.0
SN: A81001-UP-UP
2шт.
23
417-22-27380
WASHER, T2.1
SN: A81001-UP-UP
2шт.
24
417-22-27410
DISC
SN: A81001-UP-UP
4шт.
25
417-22-27450
PLATE, T3.0
SN: A81001-UP-UP
4шт.
26
417-22-27460
PLATE, T3.0
SN: A81001-UP-UP
4шт.
27
01010-31640
BOLT
SN: A81001-UP-UP
32шт.
28
07012-00065
SEAL, OIL
SN: A81001-UP-UP
1шт.
29
417-22-12850
BEARING
SN: A81001-UP-UP
2шт.
30
NSS
HOUSING
SN: A81001-UP-UP
1шт.
31
07044-13620
PLUG, DRAIN
SN: A81001-UP-UP
1шт.
32
07002-13634
O-RING
SN: A81001-UP-UP
1шт.
33
07043-70211
PLUG
SN: A81001-UP-UP
2шт.
34
419-33-11460
BLEEDER
SN: A81001-UP-UP
2шт.
35
566-32-11620
CAP
SN: A81001-UP-UP
2шт.
36
417-33-11430
RING
SN: A81001-UP-UP
2шт.
37
01010-61230
BOLT
SN: A81001-UP-UP
12шт.
38
417-22-13121
COVER
SN: A81001-UP-UP
1шт.
39
417-33-11420
O-RING
SN: A81001-UP-UP
2шт.
40
01010-61240
BOLT
SN: A81001-UP-UP
16шт.
41
01643-31232
WASHER
SN: A81001-UP-UP
16шт.
42
417-22-22610
CARRIER
SN: A81001-UP-UP
2шт.
43
417-22-11461
SHIM - 0.003 IN. (0.07 MM)
SN: A81001-UP-UP
6шт.
|$49
417-22-11471
SHIM - 0.008 IN. (0.20 MM)
SN: A81001-UP-UP
3шт.
|$50
417-22-11481
SHIM - 0.012 IN. (0.30 MM)
SN: A81001-UP-UP
3шт.
|$51
417-22-11491
SHIM - 0.031 IN. (0.80 MM)
SN: A81001-UP-UP
2шт.
44
SHAFT (SEE FIG. F4500-01A0)
SN: A81001-UP-UP
-1шт.
