AXLE ASSEMBLY, REAR(SEE FIG.F4500-01A0)
SN: A81001-UP-UP
-1шт.
1
417-33-11263
PLATE
SN: A81001-UP-UP
2шт.
2
417-33-11243
DISC
SN: A81001-UP-UP
2шт.
3
417-33-11122
PISTON
SN: A81001-UP-UP
2шт.
4
417-33-11410
O-RING
SN: A81001-UP-UP
2шт.
5
417-33-11253
PLATE
SN: A81001-UP-UP
2шт.
6
BEARING (SEE FIG. F4500-01A0)
SN: A81001-UP-UP
-1шт.
7
SEAL (SEE FIG. F4500-01A0)
SN: A81001-UP-UP
-1шт.
8
SHAFT (SEE FIG. F4500-01A0)
SN: A81001-UP-UP
-1шт.
9
WASHER (SEE FIG. F4500-05A0)
SN: A81001-UP-UP
-1шт.
10
BOLT (SEE FIG. F4500-05A0)
SN: A81001-UP-UP
-1шт.
11
GEAR (SEE FIG. F4500-01A0)
SN: A81001-UP-UP
-1шт.
12
CARRIER (SEE FIG. F4500-01A0)
SN: A81001-UP-UP
-1шт.
