1
418-06-13132
SUPPORT,L.H.
SN: 20001-UP
1шт.
2
418-06-13143
SUPPORT,R.H.
SN: 20001-UP
1шт.
3
421-06-13730
LAMP ASS'Y,REAR, COMBINATION L.H.
SN: 10001-UP
1шт.
3
421-06-13820
LAMP ASS'Y,REAR, COMBINATION R.H.
SN: 10001-UP
1шт.
3
421-06-13740
LENS,STOP LAMP
SN: 10001-UP
1шт.
3
421-06-13750
LENS,TURN SIGNAL LAMP
SN: 10001-UP
1шт.
3
08105-12420
BULB, 25W
SN: 10001-UP
1шт.
3
08104-12420
BULB, 25/10W
SN: 10001-UP
1шт.
3
08102-02403
BULB, 3W
SN: 10001-UP
1шт.
4
01010-50820
BOLT
SN: 10001-UP
4шт.
5
01643-30823
WASHER
SN: 10001-UP
8шт.
6
01580-10806
NUT
SN: 10001-UP
4шт.
7
01010-50620
BOLT
SN: 10001-UP
2шт.
8
01643-30623
WASHER
SN: 10001-UP
4шт.
9
01580-10605
NUT
SN: 10001-UP
2шт.
10
421-06-13901
LAMP ASS'Y,BACK
SN: 10001-UP
1шт.
10
421-06-13911
LENS
SN: 10001-UP
1шт.
10
08105-12420
BULB, 25W
SN: 10001-UP
1шт.
11
01580-10806
NUT,(WITH BACK LAMP)
SN: 10001-UP
2шт.
12
01643-30823
WASHER,(WITH BACK LAMP)
SN: 10001-UP
2шт.
13
418-06-13310
COVER,(WITHOUT BACK LAMP)
SN: 10001-UP
1шт.
14
01010-50816
BOLT,(WITH BACK LAMP)
SN: 10001-UP
2шт.
14
01010-51016
BOLT,(WITHOUT BACK LAMP)
SN: 10001-UP
2шт.
15
01643-30823
WASHER,(WITH BACK LAMP)
SN: 10001-UP
2шт.
15
01643-31032
WASHER,(WITHOUT BACK LAMP)
SN: 10001-UP
2шт.
16
01010-51020
BOLT
SN: 10001-UP
8шт.
17
01643-31032
WASHER
SN: 20001-UP
8шт.
18
08164-00000
BUZZER,BACK
SN: 10001-UP
1шт.
19
6132-11-6460
BOLT,(WITH BACK BUZZER)
SN: 20001-UP
2шт.
19
01011-51015
BOLT,(WITH BACK BUZZER)
SN: 10001-19999
2шт.
20
01643-30823
WASHER,(WITH BACK BUZZER)
SN: 20001-UP
2шт.
20
01643-31032
WASHER,(WITH BACK BUZZER)
SN: 10001-19999
2шт.
21
421-06-13202
WORK LAMP ASS'Y
SN: 10001-UP
2шт.
21
22W-06-12170
BULB
SN: 10001-UP
1шт.
21
421-06-13120
CUSHION
SN: 10001-UP
4шт.
22
419-06-12341
WIRE ASS'Y
SN: 20001-UP
1шт.
23
08036-10810
CLIP
SN: 10001-UP
6шт.
