Запчасти Komatsu WA200-5 КРЕСЛО ОПЕРАТОРА (SUSPENTION) (ТКАНЬ ТИП) (РЕМЕНЬ БЕЗОПАСНОСТИ W=7) (ВНУТР. ЧАСТИ) (№B-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

418-57-B1240

OPERATOR’S SEAT (SUSPENSION) (FABRIC TYPE)

SN: B10153-UP

1шт.

1

GJ18000412

HEADREST ASS'Y

SN: B10153-UP

1шт.

2

GJ18030495

HEADREST COVER ASS'Y

SN: B10153-UP

1шт.

3

GJ18030250

HEADREST FOAM ASS'Y

SN: B10153-UP

1шт.

4

GJ18000411

BACKREST ASS'Y

SN: B10153-UP

1шт.

5

GJ18030494

BACKREST COVER ASS'Y

SN: B10153-UP

1шт.

6

GJ18260394

BACKREST FOAM ASS'Y

SN: B10153-UP

1шт.

7

GJ18000410

SEATREST ASS'Y

SN: B10153-UP

1шт.

8

GJ18030493

SEATREST COVER ASS'Y

SN: B10153-UP

1шт.

9

GJ18030515

SEATREST FOAM ASS'Y

SN: B10153-UP

1шт.

10

GJ19400160

ARMREST R.H

SN: B10153-UP

1шт.

11

GJ19400159

ARMREST L.H

SN: B10153-UP

1шт.

12

GJ18240070

BACKREST FIXING ASS'Y

SN: B10153-UP

1шт.

13

GJ18210033

BACKREST SPRING ASS'Y

SN: B10153-UP

1шт.

14

GJ18180415

BACKREST FINISHING ASS'Y

SN: B10153-UP

1шт.

|15

GJ19016420

SUSPENSION ASS'Y

SN: B10153-UP

1шт.

15

0

SUSPENSION BRACKET

SN: B10153-UP

1шт.

16

GJ18210031

DAMPER ASS'Y

SN: B10153-UP

1шт.

17

GJ18240132

LEVER ASS'Y

SN: B10153-UP

1шт.

18

GJ18240077

LEVER SUB ASS'Y

SN: B10153-UP

1шт.

19

GJ18030350

SUSPENSION COVER ASS'Y

SN: B10153-UP

1шт.

20

0

SLIDER BRACKET

SN: B10153-UP

1шт.

21

GJ18180434

WEIGHT ADJUSTER ASS'Y

SN: B10153-UP

1шт.

22

GJ18210032

WEIGHT ADJUSTER SPRING

SN: B10153-UP

1шт.

23

GJ18180446

SUSPENSION ADJUSTER BELT ASS'Y

SN: B10153-UP

1шт.

24

GJ18150058

SLIDER BRACKET ASS'Y

SN: B10153-UP

1шт.

25

GJ18240083

SLIDER ASS'Y

SN: B10153-UP

1шт.

26

GJ18260019

RETRATIL 3" SEAT BELT ASS'Y

SN: B10153-UP

1шт.

27

GJ18260395

SEAT BELT ANCHOR ASS'Y

SN: B10153-UP

1шт.
