1
418-54-12510
FRAME, FLOOR
1шт.
2
419-54-12391
COVER
1шт.
3
01010-50610
BOLT
2шт.
4
01643-30623
WASHER
2шт.
5
419-54-12413
COVER
1шт.
6
01010-50816
BOLT (WITH AIR HEATER & CONDITIONER)
5шт.
7
01643-30823
WASHER (WITH AIR HEATER & CONDITIONER)
5шт.
8
419-54-13240
COVER, LH
1шт.
9
419-54-12822
COVER, RH (WITH AIR CONDITIONER)
1шт.
|$9
419-54-12911
COVER, RH (WITHOUT AIR CONDITIONER)
1шт.
10
01010-50816
BOLT
4шт.
11
01643-30823
WASHER
4шт.
12
01010-51225
BOLT (WITH AIR CONDITIONER)
1шт.
|$13
01010-51225
BOLT (WITHOUT AIR CONDITIONER)
2шт.
13
01643-31232
WASHER (WITH AIR CONDITIONER)
1шт.
|$15
01643-31232
WASHER (WITHOUT AIR CONDITIONER)
2шт.
14
419-54-12850
SHIM, 0.5mm
10шт.
|$17
419-54-12860
SHIM, 1.6mm
10шт.
15
01010-51455
BOLT
4шт.
16
01643-31445
WASHER
4шт.
17
419-54-12375
SUPPORT
1шт.
18
421-54-12273
INSULATOR
1шт.
19
419-54-12631
SHEET
1шт.
20
419-U56-1190
COVER
1шт.
21
424-09-12610
GRILLE (WITHOUT AIR CONDlTlONER)
4шт.
22
425-54-12871
COVER
1шт.
23
01010-50820
BOLT
6шт.
24
01643-30823
WASHER
6шт.
25
01224-70620
SCREW
2шт.
26
419-54-12383
COVER
1шт.
27
01010-50820
BOLT
4шт.
28
01643-30823
WASHER
4шт.
29
09415-02512
CAP
1шт.
30
01010-51230
BOLT
4шт.
31
01643-31232
WASHER
4шт.
32
419-54-12233
MAT, FLOOR
1шт.
