|$0
TRANSMISSION ASSEMBLY(SEE FIG. F4350-51A0)
SN: A70001-UP-UP
-1шт.
1
714-13-14520
SHAFT, OUTPUT
SN: A70001-UP-UP
1шт.
2
714-13-14620
GEAR, 37 TEETH - OUTPUT
SN: A70001-UP-UP
1шт.
3
04064-07025
RING, SNAP
SN: A70001-UP-UP
1шт.
4
06002-30212
BEARING
SN: A70001-UP-UP
1шт.
5
06002-32013
BEARING
SN: A70001-UP-UP
1шт.
6
419-15-13711
COVER, GEAR
SN: A70001-UP-UP
1шт.
7
01010-E1225
BOLT
SN: A70001-UP-UP
2шт.
8
01643-31232
WASHER
SN: A70001-UP-UP
2шт.
9
714-13-14110
COUPLING, FRONT
SN: A70001-UP-UP
1шт.
|$10
714-13-14320
DEFLECTOR
SN: A70001-UP-UP
1шт.
10
423-22-11240
HOLDER
SN: A70001-UP-UP
1шт.
11
01011-61610
BOLT
SN: A70001-UP-UP
1шт.
12
07000-E0255
O-RING
SN: A70001-UP-UP
1шт.
13
419-15-13650
SEAL, OIL
SN: A70001-UP-UP
1шт.
14
419-15-13650
SEAL, OIL
SN: A70001-UP-UP
1шт.
15
419-15-13660
SEAL, DUST
SN: A70001-UP-UP
1шт.
16
419-15-13660
SEAL, DUST
SN: A70001-UP-UP
1шт.
17
714-13-18610
HUB, SPLINE
SN: A70001-UP-UP
1шт.
18
714-13-14121
COUPLING, REAR
SN: A70001-UP-UP
1шт.
|$20
714-11-14320
DEFLECTOR
SN: A70001-UP-UP
1шт.
19
714-13-14271
SHIM - 0.002 IN. (0.05 MM)
SN: A70001-UP-UP
3шт.
|$22
714-13-14291
SHIM - 0.008 IN. (0.20 MM)
SN: A70001-UP-UP
2шт.
|$23
714-13-14280
SHIM - 0.197 IN. (0.50 MM)
SN: A70001-UP-UP
4шт.
|$24
714-13-14370
SHIM - 0.002 IN. (0.05 MM)
SN: A70001-UP-UP
3шт.
|$25
714-13-14390
SHIM - 0.008 IN. (0.20 MM)
SN: A70001-UP-UP
2шт.
|$26
714-13-14380
SHIM - 0.197 IN. (0.50 MM)
SN: A70001-UP-UP
4шт.
20
714-13-18311
COVER
SN: A70001-UP-UP
1шт.
21
714-13-18321
RETAINER
SN: A70001-UP-UP
1шт.
22
714-13-18691
GASKET
SN: A70001-UP-UP
1шт.
