|$0
418-23-20000
AXLE ASSEMBLY, REAR - STANDARDDIFFERENTIAL
SN: A70001-A70392-UP
1шт.
|$2
OR
-1шт.
|$4
418-23-20050
AXLE ASSEMBLY, REAR - LIMITED SLIPDIFFERENTIAL OPTION
SN: A70393-UP-UP
1шт.
1
418-22-22530
GEAR
SN: A70001-UP-UP
6шт.
2
417-22-22810
BEARING, CONE
SN: A70001-UP-UP
12шт.
3
418-22-12510
SHAFT
SN: A70001-UP-UP
6шт.
4
419-22-12570
PIN
SN: A70001-UP-UP
6шт.
5
418-22-22610
CARRIER
SN: A70001-UP-UP
2шт.
6
418-22-22350
HOLDER
SN: A70001-UP-UP
2шт.
7
418-23-23220
HOUSING, R.H.
SN: A70001-UP-UP
1шт.
8
418-23-23210
HOUSING, L.H.
SN: A70001-UP-UP
1шт.
9
815-02-10110
PLATE, NAME - LIMITED SUPPLY
SN: A70001-UP-UP
1шт.
10
04418-03060
SCREW
SN: A70001-UP-UP
4шт.
11
418-22-22420
SHAFT
SN: A70001-UP-UP
2шт.
12
418-22-12540
GEAR
SN: A70001-UP-UP
2шт.
13
419-22-12581
PIN
SN: A70001-UP-UP
6шт.
14
418-22-22450
SHAFT
SN: A70001-UP-UP
2шт.
15
418-22-12840
BEARING
SN: A70001-UP-UP
2шт.
16
418-22-12850
BEARING
SN: A70001-UP-UP
2шт.
17
01438-02000
BOLT
SN: A70001-UP-UP
2шт.
18
418-22-21460
SHIM - 0.002 IN. (0.05 MM)
SN: A70001-UP-UP
4шт.
|$23
418-22-21470
SHIM - 0.008 IN. (0.20 MM)
SN: A70001-UP-UP
4шт.
|$24
418-22-21480
SHIM - 0.020 IN. (0.50 MM)
SN: A70001-UP-UP
4шт.
19
418-22-12460
SEAL
SN: A70001-UP-UP
2шт.
20
418-33-21240
DISC
SN: A70001-UP-UP
2шт.
21
418-33-21261
PLATE
SN: A70001-UP-UP
2шт.
22
WASHER (SEE FIG. F4500-03A0)
SN: A70001-UP-UP
-1шт.
23
BOLT (SEE FIG. F4500-03A0)
SN: A70001-UP-UP
-1шт.
24
WASHER (SEE FIG. F4500-03A0)
SN: A70001-UP-UP
-1шт.
25
BOLT (SEE FIG. F4500-03A0)
SN: A70001-UP-UP
-1шт.
