|1
362-17-41402
PUMP ASS'Y,(A4VG28DA-929-0)
SN: 26001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-01A0 TO Y1610-07A0.
-1шт.
|1
705-41-06560
PUMP ASS'Y,GEAR
SN: 26001-UP
1шт.
1
0
BRACKET
SN: 26001-UP
1шт.
|1
0
BUSHING,PLANE (DRIVE SIDE)
SN: 26001-UP
1шт.
|1
0
BUSHING,PLANE (DRIVEN SIDE)
SN: 26001-UP
1шт.
2
0
CASE,GEAR
SN: 26001-UP
1шт.
3
0
CARRIER
SN: 26001-UP
1шт.
|3
0
BUSHING,PLANE (DRIVE SIDE)
SN: 26001-UP
2шт.
|3
0
BUSHING,PLANE (DRIVEN SIDE)
SN: 26001-UP
2шт.
4
0
BRACKET
SN: 26001-UP
1шт.
|4
0
BUSHING,PLANE (DRIVE SIDE)
SN: 26001-UP
1шт.
|4
0
BUSHING,PLANE (DRIVEN SIDE)
SN: 26001-UP
1шт.
5
0
GEAR,DRIVE
SN: 26001-UP
1шт.
6
0
GEAR,DRIVEN
SN: 26001-UP
1шт.
7
0
GEAR,DRIVE
SN: 26001-UP
1шт.
8
0
GEAR,DRIVEN
SN: 26001-UP
1шт.
9
0
PLATE,SIDE
SN: 26001-UP
4шт.
10
0
SEAL
SN: 26001-UP
3шт.
11
0
PIN
SN: 26001-UP
6шт.
12
705-40-80880
PLATE
SN: 26001-UP
1шт.
13
705-40-83760
SEAL
SN: 26001-UP
1шт.
14
705-40-80870
PLATE
SN: 26001-UP
1шт.
15
705-40-80810
SEAL,OIL
SN: 26001-UP
1шт.
16
04065-03515
RING,SNAP
SN: 26001-UP
1шт.
17
0
BOLT
SN: 26001-UP
4шт.
18
0
WASHER
SN: 26001-UP
4шт.
