Запчасти Komatsu WA320-3 active ГИДРОЦИЛИНДР ПОДЪЕМА ГИДРАВЛИКА
1
6
7
3
12
10
11
4
5
9
8
14
14
16
13
17
19
1A
20
2
18
15
FIT
1:1
100%
№
Артикул
Название
Примечание
Количество
5
SEAL
EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (20) Kit
1шт.
6
STRIPPER
EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (20) Kit
1шт.
8
419-63-H0P05
O-RING
EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (20) Kit
1шт.
9
419-63-H0P04
BACK-UP RING
EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (20) Kit
1шт.
13
O-RING
EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (20) Kit
1шт.
14
BACK-UP RING
EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (20) Kit
2шт.
16
419-63-H0P06
SEAL
EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (20) Kit
1шт.
17
GASKET
EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (20) Kit
1шт.
