Запчасти Komatsu WA320-3 ПЕРЕДНИЙ МОСТ(КОЖУХ МОСТА) F[ТРАНСМИССИЯ]

|$0

419-22-20013

AXLE ASS'Y, FRONT THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS. F4400-01A0 TO F4400-04A0

Field_1: 15001-

1шт.

1

419-22-23711

HOUSING. R. H

Field_1: 15001-

1шт.

2

419-22-23721

HOUSING. L. H

Field_1: 15001-

1шт.

3

815-02-Z0110

PLATE, NAME. (LIMITED SUPPLY)

Field_1: 15001-

1шт.

4

04418-13060

SCREW

Field_1: 15001-

4шт.

5

07030-01030

BREATHER

Field_1: 15001-

1шт.

6

04020-01228

PIN, DOWEL

Field_1: 15001-

4шт.

7

01011-61675

BOLT

Field_1: 15001-

32шт.

8

01643-31645

WASHER

Field_1: 15001-

32шт.

9

417-22-23250

PLUG

Field_1: 15001-

1шт.

10

07002-13034

O-RING

Field_1: 15001-

1шт.

11

419-22-13140

PLUG

Field_1: 15001-

2шт.

12

07002-13034

O-RING

Field_1: 15001-

2шт.

13

01252-30816

BOLT

Field_1: 15001-

4шт.

14

154-61-16570

WASHER

Field_1: 15001-

4шт.
