SHIFTING И CONVERTER НАСОС

Запчасти Komatsu WA320-3 SHIFTING И CONVERTER НАСОС ТРАНСМИССИЯ, КРЕСТОВИНА

Схема запчастей Komatsu WA320-3 - SHIFTING И CONVERTER НАСОС ТРАНСМИССИЯ, КРЕСТОВИНА
3
5
4
6
11
12
7
10
2
7
3
5
4
6
7
14
15
13
16
8
9
18
20
19
21
25
26
27
17
1
22
18
20
19
21
22
24
23
28
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

2

705-21-26060

HYDRAULIC PUMP

EnglischBem: SN: - 310

1шт.

3

705-17-02631

SUPPORT

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (2) Kit

2шт.

4

705-17-02440

CLAMP

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (2) Kit

2шт.

5

705-17-02472

SEAL

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

2шт.

6

705-17-02381

O-RING

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

2шт.

7

04020-01024

PIN

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

6шт.

8

705-17-02720

SCREW

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

4шт.

9

01643-51232

PLAIN WASHER

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

4шт.

10

705-17-02480

O-RING

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

1шт.

11

705-17-02374

SCREW

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit

4шт.

12

01643-51032

PLAIN WASHER

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

4шт.

13

705-17-02881

COVER

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (2) Kit

1шт.

14

07000-03038

O-RING

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (2) Kit

1шт.

15

01010-51025

SCREW

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

4шт.

16

01643-51032

PLAIN WASHER

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (2) Kit

4шт.

17

705-21-32060

HYDRAULIC PUMP

DeutschDesc: HYDRAULIKPUMPE

1шт.

18

705-17-02631

SUPPORT

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (17) Kit

2шт.

19

705-17-02440

CLAMP

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (17) Kit

2шт.

20

705-17-02472

SEAL

EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (17) Kit

2шт.

21

705-17-02381

O-RING

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (17) Kit

2шт.

22

04020-01024

PIN

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (17) Kit

4шт.

23

705-17-02780

SCREW

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (17) Kit

4шт.

24

01643-51232

PLAIN WASHER

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (17) Kit

4шт.

25

705-17-02870

DISC

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (17) Kit

1шт.

26

705-17-02810

GASKET

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (17) Kit

1шт.

27

04065-04018

CIRCLIP

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (17) Kit

1шт.

28

705-17-02310

COUPLING/CLUTCH

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (17) Kit

1шт.
