Запчасти Komatsu WA320-6 F-A HST РЕГУЛИР. НАСОС (/) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

PUMP, VARIABLE ( SEE FIG. F2430-02A0 )

SN: A35001--UP

-1шт.

|$1

UC40960793991

ROTARY GROUP

SN: A35001--UP

-1шт.

1

UC10204055651

CYLINDER BLOCK

SN: A35001--UP

1шт.

2

UC40207682941

PISTON

SN: A35001--UP

9шт.

3

UC10992172031

SPRING

SN: A35001--UP

1шт.

4

UC17044512261

CRADLE

SN: A35001--UP

1шт.

5

UC17044903491

RING, SLIDE

SN: A35001--UP

1шт.

6

UC17092170761

SHAFT

SN: A35001--UP

1шт.

7

UC17042141821

WIRE

SN: A35001--UP

2шт.

8

UC17043250531

SHIM

SN: A35001--UP

1шт.

|$10

UC17043250621

SHIM

SN: A35001--UP

1шт.

|$11

UC17043250711

SHIM

SN: A35001--UP

1шт.

|$12

UC17043250891

SHIM

SN: A35001--UP

1шт.

9

UC10992171931

PLATE, RETAINING

SN: A35001--UP

1шт.

10

UC10943226491

BALL

SN: A35001--UP

1шт.

11

UC10206659411

BEARING, LINER

SN: A35001--UP

1шт.

12

UC10992171751

WASHER

SN: A35001--UP

2шт.

13

UC17043546571

SPRING, PRESSURE

SN: A35001--UP

1шт.

14

UC17015626991

BEARING, ROLLER

SN: A35001--UP

1шт.

15

UC17083057871

BEARING ASSEMBLY

SN: A35001--UP

1шт.

16

UC17008441651

RING, RETAINING

SN: A35001--UP

1шт.

17

UC10260000291

RING, RETAINING

SN: A35001--UP

2шт.

18

UC17083098081

SEAL RING, SHAFT

SN: A35001--UP

1шт.

19

UC17008340581

RING, RETAINING

SN: A35001--UP

1шт.
