1
711-50-05011
SERVICE KIT,TORQUE CONVERTER
SN: 20001-UP
1шт.
|1
0
SERVICE KIT,TORQUE CONVERTER
SN: 10001-19999
1шт.
|1
07000-72070
O-RING,SHAFT
SN: 20001-UP
1шт.
|1
07000-02070
O-RING,SHAFT
SN: 10001-19999
1шт.
|1
711-49-05010
SHIM KIT,SHAFT
SN: 10001-UP
1шт.
|1
07000-05270
O-RING,COVER
SN: 20001-UP
1шт.
|1
0
O-RING,COVER
SN: 10001-19999
1шт.
|2
423-15-05116
SERVICE KIT,TORQFLOW TRANSMISSION
SN: (4657)-UP
1шт.
|2
423-15-05115
SERVICE KIT,TORQFLOW TRANSMISSION
SN: (4211)-(4656)
1шт.
|2
423-15-05114
SERVICE KIT,TORQFLOW TRANSMISSION
SN: (4091)-(4210)
1шт.
|2
423-15-05113
SERVICE KIT,TORQFLOW TRANSMISSION
SN: (3824)-(4090)
1шт.
|2
423-15-05112
SERVICE KIT,TORQFLOW TRANSMISSION
SN: 20001-(3823)
1шт.
|2
423-15-05111
SERVICE KIT,TORQFLOW TRANSMISSION
SN: (2419)-19999
1шт.
|2
0
SERVICE KIT,TORQFLOW TRANSMISSION
SN: 10001-(2418)
1шт.
2
423-15-05121
SERVICE KIT,TRANSMISSION
SN: 20001-UP
1шт.
|2
0
SERVICE KIT,TRANSMISSION
SN: 10001-19999
1шт.
|2
07002-02434
O-RING,PLUG
SN: 10001-UP
3шт.
|2
07000-73028
O-RING,FLANGE
SN: 10001-UP
2шт.
|2
07000-72021
O-RING,SLEEVE
SN: 10001-UP
10шт.
|2
07002-02434
O-RING,DRAIN PLUG
SN: 10001-UP
1шт.
|2
07000-02055
O-RING,OIL FILTER
SN: 10001-UP
1шт.
|2
07000-02090
O-RING,OIL FILTER
SN: 10001-UP
1шт.
|2
07000-02110
O-RING,OIL FILTER
SN: 10001-UP
2шт.
|2
07000-05290
O-RING,TRANSFER CASE
SN: 10001-UP
1шт.
|2
07000-02105
O-RING,TRANSFER CASE
SN: 10001-UP
1шт.
|2
07000-73040
O-RING,TRANSFER CASE
SN: 10001-UP
1шт.
|2
07000-33048
O-RING,TRANSFER CASE
SN: 10001-UP
1шт.
|2
113-15-12870
RING,REVERSE CLUTCH
SN: 10001-UP
1шт.
|2
124-15-41910
RING,REVERSE CLUTCH
SN: 10001-UP
1шт.
|2
124-15-41920
RING,FORWARD CLUTCH
SN: 10001-UP
1шт.
|2
103-15-12820
RING,FORWARD CLUTCH
SN: 10001-UP
1шт.
|2
232-15-19210
RING,3RD CLUTCH
SN: 10001-UP
1шт.
|2
124-15-41910
RING,3RD AND 4TH CLUTCH
SN: 10001-UP
2шт.
|2
113-15-12870
RING,4TH CLUTCH
SN: 10001-UP
1шт.
|2
423-15-19210
RING,CAGE¤ TRANSFER GEAR
SN: 10001-UP
2шт.
|2
124-15-41910
RING,1ST CLUTCH
SN: 10001-UP
1шт.
|2
124-15-41920
RING,1ST CLUTCH
SN: 10001-UP
1шт.
|2
232-15-19210
RING,2ND CLUTCH
SN: 10001-UP
1шт.
|2
103-15-12820
RING,2ND CLUTCH
SN: 10001-UP
1шт.
|2
423-15-05010
SHIM ASS'Y,CAGE¤ TRANSFER GEAR
SN: 10001-UP
1шт.
|2
07000-02130
O-RING,COVER¤ TRANSFER GEAR
SN: 10001-UP
1шт.
|2
232-15-13450
GASKET,COVER¤ TRANSFER GEAR
SN: 10001-19999
1шт.
|2
423-15-13910
O-RING,CAGE¤ TRANSFER GEAR
SN: 10001-UP
1шт.
|2
423-15-05020
SHIM ASS'Y,CAGE¤ TRANSFER GEAR
SN: 10001-UP
1шт.
|2
07000-02105
O-RING,COVER¤ TRANSFER GEAR
SN: 10001-UP
1шт.
|2
07012-10085
SEAL,OIL¤ OUTPUT SHAFT
SN: 10001-UP
2шт.
|2
07000-05125
O-RING,CAGE¤ TRANSFER GEAR
SN: 10001-UP
1шт.
|2
424-15-05010
SHIM ASS'Y,CAGE¤ TRANSFER GEAR
SN: 10001-UP
1шт.
|2
07000-05055
O-RING,COUPLING
SN: 10001-UP
1шт.
|2
07000-05300
O-RING,CAGE¤ TRANSFER GEAR
SN: 10001-UP
1шт.
|2
07000-73022
O-RING,PIPING
SN: 10001-UP
1шт.
|2
07002-02034
O-RING,PIPING
SN: 10001-UP
2шт.
|2
07000-73022
O-RING,PIPING
SN: 10001-UP
1шт.
3
423-15-05136
SERVICE KIT,TRANSMISSION VALVE
SN: (4657)-UP
1шт.
|3
423-15-05135
SERVICE KIT,TRANSMISSION VALVE
SN: (4211)-(4656)
1шт.
|3
423-15-05134
SERVICE KIT,TRANSMISSION VALVE
SN: (4091)-(4210)
1шт.
|3
423-15-05133
SERVICE KIT,TRANSMISSION VALVE
SN: (3824)-(4090)
1шт.
|3
423-15-05132
SERVICE KIT,TRANSMISSION VALVE
SN: 20001-(3823)
1шт.
|3
423-15-05131
SERVICE KIT,TRANSMISSION VALVE
SN: (2419)-19999
1шт.
|3
423-15-05130
SERVICE KIT,TRANSMISSION VALVE
SN: 10001-(2418)
1шт.
|3
07000-72021
O-RING,UPPER VALVE
SN: 10001-UP
1шт.
|3
424-15-15930
GASKET,UPPER VALVE
SN: 10001-UP
1шт.
|3
07000-73030
O-RING,UPPER VALVE
SN: 10001-UP
1шт.
|3
07000-73035
O-RING,UPPER VALVE
SN: 10001-UP
1шт.
|3
07000-72015
O-RING,UPPER VALVE
SN: 10001-UP
1шт.
|3
07000-71009
O-RING,UPPER VALVE
SN: 10001-UP
1шт.
|3
07000-72021
O-RING,UPPER VALVE
SN: 10001-(4090)
1шт.
|3
07000-73030
O-RING,UPPER VALVE
SN: 10001-(4090)
2шт.
|3
07002-03034
O-RING,UPPER VALVE
SN: 10001-(4090)
1шт.
|3
07000-72015
O-RING,UPPER VALVE
SN: 10001-(2418)
2шт.
|3
424-15-15982
GASKET,UPPER VALVE
SN: (3824)-UP
1шт.
|3
424-15-15981
GASKET,UPPER VALVE
SN: 20001-(3823)
1шт.
|3
424-15-15980
GASKET,UPPER VALVE
SN: 10001-19999
1шт.
|3
424-15-15960
GASKET,LOWER VALVE
SN: 10001-UP
1шт.
|3
424-15-15920
GASKET,LOWER VALVE
SN: 10001-UP
1шт.
|3
07002-03034
O-RING,LOWER VALVE
SN: 10001-UP
1шт.
|3
424-15-15992
GASKET,LOWER VALVE
SN: (4091)-UP
1шт.
|3
424-15-15991
GASKET,LOWER VALVE
SN: 20001-(4090)
1шт.
|3
424-15-15990
GASKET,LOWER VALVE
SN: 10001-19999
1шт.
|3
424-15-17230
GASKET,SOLENOID VALVE
SN: (4211)-UP
1шт.
|3
22W-06-15690
GASKET,SOLENOID VALVE
SN: 20001-(4210)
1шт.
|3
568-15-15880
GASKET,SOLENOID VALVE
SN: 10001-19999
1шт.
|3
07000-71009
O-RING,SOLENOID VALVE
SN: 10001-UP
6шт.
|3
568-15-17260
O-RING,SOLENOID VALVE
SN: 10001-UP
1шт.
|3
07000-31006
O-RING,SOLENOID VALVE
SN: 10001-UP
1шт.
|3
424-15-17141
GASKET,SOLENOID VALVE
SN: (4657)-UP
1шт.
|3
424-15-17140
GASKET,SOLENOID VALVE
SN: 10001-(4656)
1шт.
|3
424-15-17121
GASKET,SOLENOID VALVE
SN: 10001-UP
1шт.
|3
0
GASKET,SOLENOID VALVE
SN: (10001-(3823))
1шт.
4
423-22-05010
SERVICE KIT,DIFFERENTIAL
SN: 10001-UP
2шт.
|4
07002-03634
O-RING,DRAIN PLUG
SN: 10001-UP
1шт.
|4
07002-03634
O-RING,PLUG
SN: 20001-UP
2шт.
|4
07002-03634
O-RING,PLUG
SN: 10001-19999
1шт.
|4
07000-02145
O-RING,CAGE
SN: 10001-UP
1шт.
|4
07000-05160
O-RING,CAGE
SN: 10001-UP
1шт.
|4
07012-00085
SEAL,OIL¤ CAGE
SN: 20034-UP
1шт.
|4
0
SEAL,OIL¤ CAGE
SN: 10001-20033
1шт.
|4
423-22-11760
SEAL,DUST¤ CAGE
SN: 11205-UP
1шт.
|4
423-09-11110
O-RING,COUPLING
SN: 10001-UP
1шт.
|4
07000-05405
O-RING,CARRIER
SN: 10001-UP
1шт.
5
423-33-05012
SERVICE KIT,WHEEL BRAKE
SN: 20001-UP
2шт.
|5
07002-01423
O-RING,PLUG
SN: 20001-UP
4шт.
|5
423-33-11430
SEAL,PISTON
SN: 20001-UP
2шт.
|5
423-33-11440
SEAL,PISTON
SN: 20001-UP
2шт.
|5
07002-02434
O-RING,PLUG
SN: 20001-UP
16шт.
|5
07000-05420
O-RING,CYLINDER
SN: 20001-UP
2шт.
|5
07000-02016
O-RING,CYLINDER
SN: 20001-UP
2шт.
|5
07000-05230
O-RING,CYLINDER
SN: 20001-UP
2шт.
6
421-22-05020
SERVICE KIT,FINAL DRIVE
SN: 20001-UP
2шт.
|6
07002-02434
O-RING,DRAIN PLUG
SN: 20001-UP
2шт.
|6
07000-05410
O-RING,CARRIER
SN: 20001-UP
2шт.
|6
07002-03634
O-RING,COVER
SN: 20001-UP
2шт.
|6
07000-05280
O-RING,PLUG
SN: 20001-UP
2шт.
7
281-34-05211
SERVICE KIT,CHECK VALVE (FOR 281-34-11511)
SN: 10001-19999
3шт.
|7
281-34-11561
SPRING
SN: 10001-19999
1шт.
|7
281-34-11550
VALVE
SN: 10001-19999
1шт.
|7
281-34-11540
SEAT
SN: 10001-19999
1шт.
8
281-34-05220
SERVICE KIT,(FOR 281-34-12300)
SN: 20001-UP
1шт.
|8
281-34-05220
SERVICE KIT,(FOR 281-34-12300)
SN: 10001-19999
2шт.
|8
281-34-12310
SHUTTLE,SHUTTLE
SN: 10001-UP
1шт.
|8
281-34-12320
GASKET
SN: 10001-UP
1шт.
9
281-34-05220
SERVICE KIT,(FOR 421-35-14350)
SN: 20001-UP
1шт.
|9
281-34-12310
SHUTTLE,SHUTTLE
SN: 20001-UP
1шт.
|9
281-34-12320
GASKET
SN: 20001-UP
1шт.
10
281-34-05110
SERVICE KIT,GOVERNOR
SN: 10001-UP
1шт.
|10
565-44-16120
FILTER
SN: 10001-UP
2шт.
|10
0
O-RING
SN: 10001-UP
1шт.
|10
0
VALVE,PRESSURE REGULATOR
SN: 10001-UP
1шт.
|10
0
SPRING,VALVE
SN: 10001-UP
1шт.
|10
0
O-RING
SN: 10001-UP
2шт.
|10
565-44-16240
COVER
SN: 10001-UP
1шт.
11
238-44-05030
SERVICE KIT,TREADLE VALVE
SN: 10001-UP
2шт.
|11
0
VALVE,UPPER
SN: 10001-UP
1шт.
|11
0
O-RING,RETAINER
SN: 10001-UP
1шт.
|11
0
RING,RETAINING
SN: 10001-UP
1шт.
|11
0
O-RING,RETAINER
SN: 10001-UP
1шт.
|11
0
RING,SNAP
SN: 10001-UP
1шт.
|11
0
O-RING,PISTON RELAY
SN: 10001-UP
1шт.
|11
0
O-RING,PISTON RELAY
SN: 10001-UP
1шт.
|11
0
SPRING,RUBBER
SN: 10001-UP
1шт.
|11
0
O-RING,PISTON UPPER
SN: 10001-UP
1шт.
|11
0
VALVE,LOWER
SN: 10001-UP
1шт.
|11
0
O-RING,RETAINER
SN: 10001-UP
1шт.
|11
0
RING,RETAINING
SN: 10001-UP
1шт.
|11
0
O-RING,RETAINING
SN: 10001-UP
1шт.
|11
0
VALVE,EXHAUST
SN: 10001-UP
1шт.
|11
0
O-RING,BODY
SN: 10001-UP
1шт.
12
421-35-05110
SPRING KIT,TREADLE VALVE¤ SPRING
SN: 20001-UP
1шт.
|12
238-44-05010
SERVICE KIT,TREADLE VALVE¤ SPRING
SN: 10001-19999
1шт.
|12
0
SPRING,VALVE¤ UPPER
SN: 10001-UP
1шт.
|12
0
SPRING,PISTON RELAY
SN: 10001-UP
1шт.
|12
0
SPRING,PISTON UPPER
SN: 10001-UP
1шт.
|12
0
SPRING,INNER
SN: 10001-UP
1шт.
|12
0
SPRING,OUTER
SN: 10001-UP
1шт.
|12
0
SPRING,RETAINING
SN: 10001-19999
1шт.
13
423-35-15110
SERVICE KIT,AIR DRYER
SN: 10001-19999
1шт.
|13
421-35-15470
FILTER,OIL
SN: 10001-19999
1шт.
|13
421-35-15480
GASKET
SN: 10001-19999
1шт.
|13
421-35-15460
GASKET
SN: 10001-19999
1шт.
|13
421-35-15450
FILTER
SN: 10001-19999
1шт.
|13
421-35-15360
DESICCANT
SN: 10001-19999
1шт.
|13
421-35-15370
RING,SEAL
SN: 10001-19999
1шт.
|13
421-35-15620
O-RING
SN: 10001-19999
1шт.
|13
421-35-16500
O-RING
SN: 10001-19999
1шт.
|13
423-35-16130
O-RING
SN: 10001-19999
1шт.
|13
423-35-16120
O-RING
SN: 10001-19999
1шт.
|13
423-35-16110
O-RING
SN: 10001-19999
1шт.
|13
423-35-16140
VALVE ASS'Y
SN: 10001-19999
1шт.
14
424-35-05111
SERVICE KIT,BRAKE CHAMBER
SN: 11219-UP
2шт.
|14
424-35-05110
SERVICE KIT,BRAKE CHAMBER
SN: 10001-11218
2шт.
|14
424-35-15590
RING
SN: 10001-UP
1шт.
|14
424-35-15440
PACKING
SN: 10001-UP
2шт.
|14
424-35-15450
SEAT
SN: 10001-UP
1шт.
|14
424-35-15460
PACKING
SN: 10001-UP
1шт.
|14
07000-01007
O-RING
SN: 10001-UP
1шт.
|14
424-35-15420
RING
SN: 10001-UP
1шт.
|14
424-35-15410
PACKING
SN: 10001-UP
1шт.
|14
07000-02012
O-RING
SN: 10001-UP
1шт.
|14
424-35-15480
O-RING
SN: 10001-UP
1шт.
|14
424-35-15530
VALVE
SN: 10001-UP
1шт.
|14
424-35-15540
SPRING
SN: 10001-UP
1шт.
|14
424-35-15510
PACKING
SN: 10001-UP
1шт.
|14
424-35-15561
O-RING
SN: 11219-UP
1шт.
|14
0
O-RING
SN: 10001-11218
1шт.
15
424-35-05120
SERVICE KIT,SLACK ADJUSTER
SN: 10001-UP
2шт.
|15
424-35-15280
O-RING
SN: 10001-UP
1шт.
|15
424-35-15250
COVER
SN: 10001-UP
2шт.
|15
424-35-15240
O-RING
SN: 10001-UP
2шт.
|15
424-35-15260
O-RING
SN: 10001-UP
2шт.
16
416-64-15500
SERVICE KIT,STEERING VALVE
SN: 20001-UP
1шт.
|16
416-64-15520
O-RING
SN: 20001-UP
3шт.
|16
416-64-15450
O-RING
SN: 20001-UP
1шт.
|16
416-64-15430
O-RING
SN: 20001-UP
1шт.
|16
416-64-15580
SEAL
SN: 20001-UP
1шт.
|16
416-64-15590
RING,BACK-UP
SN: 20001-UP
1шт.
|16
416-64-15570
O-RING
SN: 20001-UP
1шт.
|16
416-64-15560
O-RING
SN: 20001-UP
1шт.
|16
416-64-15550
SEAL,DUST
SN: 20001-UP
1шт.
