|$0
700-93-47003
VALVE ASSY, THREE SPOOL
1шт.
1
NSS
BODY, VALVE
1шт.
2
07040-13618
PLUG
1шт.
3
07002-13634
O-RING
1шт.
4
700-22-11360
PLUG
2шт.
5
07002-02434
O-RING
2шт.
6
07000-02014
O-RING
2шт.
7
NSS
SPOOL, DUMP AND ATTACHMENT
2шт.
8
NSS
SPOOL, LIFT
1шт.
9
700-93-11870
RETAINER, SPRING (DUMP AND ATTACHMENT SPOOL)
2шт.
10
700-93-11960
RETAINER, SPRING (DUMP AND ATTACHMENT SPOOL)
2шт.
11
700-92-11240
RETAINER, SPRING (LIFT SPOOL)
1шт.
12
700-92-11250
RETAINER, SPRING (LIFT SPOOL)
1шт.
13
700-93-11580
SPRING, LIFT-DUMP-ATTACHMENT SPOOLS
3шт.
14
01252-31016
BOLT
3шт.
15
01643-31032
WASHER
3шт.
16
700-93-11920
COVER, LIFT-DUMP-ATTACHMENT SPOOLS
3шт.
17
07430-71380
O-RING
3шт.
18
01252-30820
BOLT, MOUNT SPOOL COVERS
6шт.
19
700-92-11260
JOINT
3шт.
20
700-93-11710
CASE, LEVER MOUNTING
3шт.
21
700-93-11720
COLLAR
3шт.
22
07430-71380
O-RING
3шт.
23
700-93-11720
BOLT, MOUNT LEVER CASE
12шт.
24
700-93-11740
BEARING
3шт.
25
700-93-11750
BEARING
3шт.
26
700-93-11762
SEAL
3шт.
27
700-92-11270
LEVER
3шт.
28
04010-00416
KEY, MOUNT LEVER
3шт.
29
700-93-11780
LEVER
3шт.
30
01010-30825
BOLT, MOUNT LEVER
3шт.
31
700-93-11790
COVER, LEVER CASE
3шт.
32
700-93-11810
GASKET
3шт.
33
01010-30820
BOLT, MOUNT COVER
12шт.
34
700-93-11461
VALVE, CHECK
3шт.
35
700-93-11471
SPRING, CHECK VALVE
3шт.
36
700-93-11481
PLUG, CHECK VALVE
3шт.
37
07002-13634
O-RING
3шт.
38
700-93-11350
PLUG
1шт.
39
700-93-11320
O-RING
1шт.
40
700-93-11330
RING, BACK-UP
1шт.
41
07002-03634
O-RING
1шт.
42
700-93-12111
FLANGE
1шт.
43
07000-03035
O-RING
1шт.
44
01010-51025
BOLT, MOUNT FLANGE
2шт.
45
VALVE, MAIN RELIEF (SEE PG 06-026)
-29шт.
46
VALVE, SUCTION SAFETY (SEE PG 06-028)
-29шт.
47
VALVE, SUCTION SAFETY (SEE PG 06-030)
-29шт.
48
VALVE, SUCTION (SEE PG 06-032)
-29шт.
