1
423-877-1310
TUBE, L.H. - CONTROL VALVE TO BOOM HOSE
1шт.
|$1
07372-21035
BOLT, TUBE TO CONTROL VALVE
4шт.
|$2
01643-51032
WASHER
4шт.
2
423-877-1320
TUBE, R.H. - CONTROL VALVE TO BOOM HOSE
1шт.
|$4
07372-21035
BOLT, TUBE TO CONTROL VALVE
4шт.
|$5
01643-51032
WASHER
4шт.
3
07000-13035
RING, SEALING
2шт.
4
423-877-1212
ANGLE, CLAMP TUBE TO FRONT FRAME
2шт.
|$8
01435-01035
BOLT, MOUNT ANGLE TO FRAME
4шт.
5
07283-33450
U-BOLT, CLAMP TUBES
8шт.
|$10
01643-31032
WASHER
16шт.
|$11
01597-01009
NUT
16шт.
6
07283-53444
SEAT
8шт.
7
07125-01014
HOSE
2шт.
8
07000-13032
RING, SEALING
6шт.
9
07371-31049
FLANGE, SPLIT
12шт.
|$16
07372-21035
BOLT, MOUNT SPLIT FLANGE
24шт.
|$17
01643-51032
WASHER
24шт.
9A
07378-11000
HEAD
2шт.
10
423-878-1190
TUBE, BOOM HOSE TO FRONT ATTACHMENT
2шт.
11
423-877-1160
BRACKET, L.H. TOP - CLAMP TUBE TO BOOM
1шт.
|$21
01435-01220
BOLT, MOUNT BRACKET TO BOOM
2шт.
12
423-877-1170
BRACKET, L.H. BOTTOM - CLAMP TUBE TO BOOM
1шт.
|$23
01435-01220
BOLT, MOUNT BRACKET TO BOOM
2шт.
13
423-877-1170
BRACKET, R.H. TOP - CLAMP TUBE TO BOOM
1шт.
|$25
01435-01220
BOLT, MOUNT BRACKET TO BOOM
2шт.
14
423-877-1160
BRACKET, R.H. BOTTOM - CLAMP TUBE TO BOOM
1шт.
|$27
01435-01220
BOLT, MOUNT BRACKET TO BOOM
2шт.
15
423-877-1330
BRACKET, L.H. TUBE
1шт.
|$29
423-877-1340
BRACKET, R.H. TUBE
1шт.
16
423-70-11152
ARM, LIFT (MODIFIED PART)
1шт.
17
423-46-11151
FRAME, FRONT (MODIFIED PART)
1шт.
18
423-46-11161
COVER, FRONT ACCESS (MODIFIED PART)
1шт.
19
VALVE, 3 SPOOL CONTROL (SEE PG 06-022)
-29шт.
