Запчасти Komatsu WA380-1LC ПОРШЕНЬ & ШАТУН БЛОК ЦИЛИНДРОВ

|$0

1240 906 H91

ROD, ENGINE CONNECTING

6шт.

1

NSS

ROD, CONNECTING

1шт.

2

1240 903 H1

BOLT, CONNECTING ROD

2шт.

3

6742-01-2730

NUT, HEX - M12

2шт.

4

6742-01-2740

BUSHING

1шт.

5

6742-01-2750

BEARING, ROD HALF - STD

12шт.

|$6

6742-01-2810

BEARING, ROD HALF - 0.25MM OVERSIZE

12шт.

|$7

6742-01-2820

BEARING, ROD HALF - 0.50MM OVERSIZE

12шт.

|$8

6742-01-2830

BEARING, ROD HALF - 0.75MM OVERSIZE

12шт.

|$9

6742-01-2840

BEARING, ROD HALF - 1.00MM OVERSIZE

12шт.

|$10

1295 691 H91

KIT, ENGINE PISTON

6шт.

6

NSS

PISTON, ENGINE

1шт.

7

6742-01-2780

RING, RETAINING

2шт.

8

1241 180 H1

SET, PISTON RING

1шт.

9

6742-01-2800

PIN, PISTON

6шт.

|$$16

-1шт.

|$16

CYLINDER KIT

-1шт.

|$17

1295 692 H91

KIT, CYLINDER

6шт.

|$18

1241 175 H92

KIT, LINER

1шт.

|$19

1295 691 H91

KIT, ENGINE PISTON

1шт.
