1
CLEANER, AIR (SEE PG 01-022)
-29шт.
2
424-01-11440
NIPPLE
1шт.
3
424-01-11280
JOINT
1шт.
4
07834-00410
ELBOW
1шт.
5
07831-00411
SLEEVE
2шт.
6
07832-00410
NUT, SLEEVE
2шт.
7
07822-00407
TUBE
1шт.
8
07836-00410
CONNECTOR
1шт.
9
08670-02001
INDICATOR, AIR CLEANER SERVICE
1шт.
10
08034-00876
BAND
1шт.
11
423-01-A1230
BRACKET, AIR CLEANER MOUNTING
1шт.
|$11
419-01-A1210
STUD, BRACKET MOUNTING
2шт.
|$12
01643-31232
WASHER
2шт.
|$13
01580-01210
NUT
2шт.
|$14
427-62-15260
BOLT, BRACKET MOUNTING
2шт.
|$15
01010-51030
BOLT, MOUNTING
2шт.
|$16
01643-31032
WASHER
2шт.
12
423-02-11210
HOSE, AIR CLEANER TO TURBOCHARGER
1шт.
13
690 069 C1
CLAMP, HOSE - AT AIR CLEANER
1шт.
14
1252 151 H1
CLAMP, HOSE - AT TURBOCHARGER
1шт.
15
6151-11-4840
BAND, AIR CLEANER MOUNTING
2шт.
16
423-02-11130
SCREEN, INTAKE
1шт.
17
6643-11-4641
BOLT, MOUNTING BAND
2шт.
18
419-01-A1180
BRACKET, SUPPORT
1шт.
|$24
01010-51030
BOLT, MOUNTING
4шт.
|$25
01643-31032
WASHER
4шт.
19
366 078 C1
INDICATOR, AIR CLEANER SERVICE
1шт.
20
175 733 H1
CONNECTOR
1шт.
21
182 866 H1
ELBOW, FEMALE
1шт.
22
105 404
NIPPLE, 1/8 X 3/4 PIPE
1шт.
