Запчасти Komatsu WA380-3L ПЕРЕДН. ПРИВОД COVER E-

1

1240 140 H1

BOLT (M8x1.25x16)

16шт.

2

1240 144 H1

BOLT (M8x1.25x50)

6шт.

3

1241 110 H1

BOLT (M12x1.75x50)

4шт.

4

1240 383 H1

SCREW, ROUND HEAD

2шт.

5

1240 240 H1

PIN, TIMING

1шт.

6

1240 296 H1

RING, RETAINING

1шт.

7

1258 943 H91

HOUSING, TIMING PIN

1шт.

8

1241 283 H1

SEAL, O-RING

1шт.

9

1278 593 H3

GASKET, GEAR HOUSING

1шт.

10

1241 284 H2

SEAL, RECTANGULAR RING

1шт.

11

1241 247 H93

HOUSING, GEAR

1шт.

12

1241 282 H2

GASKET, GEAR COVER

1шт.

|$12

1241 214 H92

KIT, FRONT GEAR COVER SERVICE

1шт.

13

NSS

SEAL, OIL

1шт.

14

1294 935 H91

COVER, GEAR

1шт.

15

1240 141 H1

BOLT (M8x1.25x20)

5шт.

N/I

1257 939 H1

PLUG, EXPANSION

1шт.

|$$18

-1шт.

|$18

F1 - INCLUDES INSTALLATION TOOLS.

-1шт.

|$$20

-1шт.
