|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$11
714-12-20004
TRANSMISSION ASS'Y
SN: 62274-UP
1шт.
|$12
714-12-20003
TRANSMISSION ASS'Y
SN: (10320)-00062273
1шт.
|$13
0
TRANSMISSION ASS'Y
SN: ((10320)-(111306))
1шт.
|$14
0
TRANSMISSION ASS'Y
SN: ((10320)-(111258))
1шт.
|$15
714-12-20000
TRANSMISSION ASS'Y
SN: 60001-(10319)
1шт.
|$16
714-12-20014
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 62274-UP
1шт.
|$17
0
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: (10320)-00062273
1шт.
|$18
0
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: ((10320)-(111306))
1шт.
|$19
0
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: ((10320)-(111258))
1шт.
|$20
714-12-20010
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 60001-(10319)
1шт.
|$21
714-12-20303
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: 62274-UP
1шт.
|$22
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: 60001-62273
1шт.
|$23
0
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: (60001-(111306))
1шт.
|$24
0
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: (60001-(111258))
1шт.
|$25
714-12-20313
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)
SN: 62274-UP
1шт.
|$26
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)
SN: 60001-62273
1шт.
|$27
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)
SN: (60001-(111306))
1шт.
|$28
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)
SN: (60001-(111258))
1шт.
|$$20
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
|$45
714-12-22032
CLUTCH ASS'Y,2ND AND 3RD
SN: 60001-UP
1шт.
|$46
0
CLUTCH ASS'Y,2ND AND 3RD
SN: (60001-(111160))
1шт.
1
714-12-22133
SHAFT,2ND AND 3RD
SN: 60001-UP
1шт.
1
0
SHAFT AND CYLINDER A,2ND AND 3RD
SN: (60001-(111160))
1шт.
1
0
SHAFT,LOWER
SN: (111161)-UP
1шт.
1
0
SHAFT,LOWER
SN: 60001-(111160)
1шт.
1
0
ORIFICE
SN: 60001-UP
1шт.
1
0
BALL
SN: 60001-UP
2шт.
1
0
HOUSING
SN: (110377)-UP
1шт.
1
0
HOUSING
SN: 60001-(110376)
1шт.
1
0
ORIFICE
SN: 60001-UP
1шт.
2
714-07-22661
PISTON,RANGE
SN: 60001-UP
2шт.
3
714-12-19711
DISC
SN: 60001-UP
14шт.
4
714-16-19730
PLATE,SEPARATE
SN: 60001-UP
16шт.
5
56D-15-12710
SPRING,WAVE
SN: (110527)-UP
14шт.
5
0
SPRING,WAVE
SN: 60001-(110526)
14шт.
6
714-12-12610
PLATE,END
SN: 60001-UP
2шт.
7
419-15-12140
RING,SNAP
SN: 60001-UP
2шт.
8
714-16-19220
RING (K1)
SN: 60001-UP
2шт.
9
714-07-19320
RING,SEAL (K1)
SN: 60001-UP
2шт.
10
714-08-19570
WASHER,THRUST
SN: (111161)-UP
3шт.
10
714-08-19570
WASHER,THRUST
SN: 60001-(111160)
4шт.
11
714-12-39570
THRUST WASHER
SN: (111161)-UP
1шт.
12
714-23-19430
BEARING,NEEDLE
SN: 60001-UP
2шт.
13
714-12-22462
GEAR, 53 TEETH,2ND
SN: 60001-UP
1шт.
13
0
GEAR, 53 TEETH,2ND
SN: (60001-(111160))
1шт.
14
714-12-22451
GEAR, 40 TEETH,3RD
SN: 60001-UP
1шт.
15
714-12-22532
GEAR, 49 TEETH,OUTPUT
SN: (111161)-UP
1шт.
15
714-12-22530
GEAR, 49 TEETH,OUTPUT
SN: 60001-(111160)
1шт.
16
714-12-22541
GEAR, 28 TEETH,4TH
SN: 60001-UP
1шт.
17
14X-14-19123
BEARING
SN: 60001-UP
1шт.
18
714-07-29340
BEARING
SN: (111161)-UP
1шт.
18
714-07-29350
BEARING
SN: 60001-(111160)
1шт.
19
569-15-49530
RING
SN: (111161)-UP
1шт.
20
419-15-12122
RING (K1)
SN: 60001-UP
3шт.
