|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$7
714-12-20004
TRANSMISSION ASS'Y
SN: 62274-UP
1шт.
|$8
714-12-20003
TRANSMISSION ASS'Y
SN: (10320)-00062273
1шт.
|$9
0
TRANSMISSION ASS'Y
SN: ((10320)-(111306))
1шт.
|$10
0
TRANSMISSION ASS'Y
SN: ((10320)-(111258))
1шт.
|$11
714-12-20000
TRANSMISSION ASS'Y
SN: 60001-(10319)
1шт.
|$12
714-12-20014
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 62274-UP
1шт.
|$13
0
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: (10320)-00062273
1шт.
|$14
0
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: ((10320)-(111306))
1шт.
|$15
0
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: ((10320)-(111258))
1шт.
|$16
714-12-20010
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 60001-(10319)
1шт.
|$$12
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
1
714-07-25401
VALVE ASS'Y,FLOW CONTROL
SN: (110435)-UP
1шт.
1
0
VALVE ASS'Y,FLOW CONTROL
SN: 60001-(110434)
1шт.
2
01252-31065
BOLT
SN: 60001-UP
1шт.
3
01252-31055
BOLT
SN: 60001-UP
3шт.
4
07000-73040
O-RING (K1)
SN: 60001-UP
1шт.
5
714-07-25021
VALVE ASS'Y,MAIN
SN: 61142-UP
1шт.
5
0
VALVE ASS'Y,MAIN
SN: (61142-(112110))
1шт.
5
0
VALVE ASS'Y,MAIN
SN: 60001-61141
1шт.
5
0
VALVE ASS'Y,MAIN
SN: (60001-60352)
1шт.
5
714-07-25031
VALVE ASS'Y,(WITH LOCK-UP)
SN: 61142-UP
1шт.
5
0
VALVE ASS'Y,(WITH LOCK-UP)
SN: (61142-(112110))
1шт.
5
0
VALVE ASS'Y,(WITH LOCK-UP)
SN: 60001-61141
1шт.
5
0
VALVE ASS'Y,(WITH LOCK-UP)
SN: (60001-60352)
1шт.
6
01010-81055
BOLT
SN: 60001-UP
6шт.
7
01643-31032
WASHER
SN: 60001-UP
6шт.
8
01011-81020
BOLT
SN: 60001-UP
1шт.
9
01643-31032
WASHER
SN: 60001-UP
1шт.
10
01011-81005
BOLT
SN: 60001-UP
2шт.
11
01643-31032
WASHER
SN: 60001-UP
2шт.
12
01011-81010
BOLT
SN: 60001-UP
1шт.
13
01643-31032
WASHER
SN: 60001-UP
1шт.
14
07000-73028
O-RING (K1)
SN: 60001-UP
3шт.
15
07000-72015
O-RING (K1)
SN: 60001-UP
25шт.
16
07000-72012
O-RING (K1)
SN: 60001-UP
2шт.
17
07000-73045
O-RING (K1)
SN: 60001-UP
1шт.
