|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-12-20001
TRANSMISSION ASS'Y
SN: (10320)-UP
1шт.
|1
714-12-20000
TRANSMISSION ASS'Y
SN: 60001-(10319)
1шт.
|1
714-12-20011
TRANSMISSION ASS'Y
SN: (10320)-UP
1шт.
|1
714-12-20010
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 60001-(10319)
1шт.
|1
714-12-20101
TRANSMISSION ASS'Y
SN: (10320)-UP
1шт.
|1
714-12-20100
TRANSMISSION ASS'Y,(FOR TACHOGRAPH)
SN: 60001-(10319)
1шт.
|1
714-12-20111
TRANSMISSION ASS'Y
SN: (10320)-UP
1шт.
|1
714-12-20110
TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND LOCK-UP)
SN: 60001-(10319)
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
|1
714-12-25002
VALVE ASS'Y,MAIN
SN: 60001-UP
1шт.
|$$12
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-59A0 AND F4350-60A0.
-1шт.
|1
714-12-25012
VALVE ASS'Y,(WITH LOCK-UP)
SN: 60001-UP
1шт.
|$$14
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-59A1 AND F4350-60A0.
-1шт.
|1
714-07-26000
VALVE ASS'Y
SN: (10320)-UP
1шт.
|1
0
VALVE ASS'Y,MODULATION
SN: 60001-(10319)
1шт.
1
17A-15-25131
BODY
SN: 60001-UP
1шт.
2
07042-20108
PLUG
SN: 60001-UP
2шт.
3
14X-15-15850
PLUG
SN: 60001-UP
1шт.
4
07002-03034
O-RING (K2)
SN: 60001-UP
1шт.
5
714-07-25230
VALVE
SN: (10320)-UP
1шт.
|5
0
VALVE
SN: 60001-(10319)
1шт.
6
426-15-15490
VALVE
SN: 60001-UP
1шт.
7
198-15-15770
SPRING¤ (L= 30.0)
SN: 60001-UP
1шт.
8
426-15-15480
VALVE
SN: 60001-UP
1шт.
9
198-15-15570
SHIM¤ 0.50MM
SN: 60001-UP
5шт.
10
426-15-16251
SPRING¤ (L=122.0)
SN: 60001-UP
1шт.
11
426-15-16261
SPRING¤ (L=108.0)
SN: 60001-UP
1шт.
12
426-15-15810
PLUG
SN: 60001-UP
1шт.
13
07002-03034
O-RING (K2)
SN: 60001-UP
1шт.
14
12H-15-14130
SPOOL
SN: 60001-UP
1шт.
15
104-15-25490
VALVE
SN: 60001-UP
1шт.
16
125-15-15290
SPRING
SN: 60001-UP
1шт.
17
104-15-25480
VALVE
SN: 60001-UP
1шт.
18
14X-15-16210
SPRING
SN: 60001-UP
1шт.
19
12H-15-14140
GUIDE
SN: 60001-UP
1шт.
20
14X-15-15850
PLUG
SN: 60001-UP
2шт.
21
07002-03034
O-RING (K2)
SN: 60001-UP
2шт.
