1
56E-07-21132
CONDENSER ASS'Y,(SEE FIG. C0110-03A0)
SN: 65001-UP
1шт.
2
423-07-31563
CONTROL PANEL A.,(SEE FIG. K0210-20A0)
SN: 65738-UP
1шт.
2
423-07-31562
CONTROL PANEL A.,(SEE FIG. K0210-20A0)
SN: 65001-65737
1шт.
3
423-S62-4171
HOSE,(SEE FIG. K0210-38A0)
SN: 65001-UP
1шт.
4
AN51439-D0051
O-RING
SN: 65001-UP
2шт.
5
423-S62-4161
HOSE,(SEE FIG. K0210-38A0)
SN: 65001-UP
1шт.
6
AN51439-D0031
O-RING
SN: 65001-UP
2шт.
7
423-S62-3370
PLATE,(SEE FIG. K0210-38A0)
SN: 65001-UP
1шт.
8
423-07-31340
HOSE,(SEE FIG. K0210-38A0)
SN: 65001-UP
1шт.
9
423-07-31350
HOSE,(SEE FIG. K0210-38A0)
SN: 65001-UP
1шт.
10
423-S62-4241
HOSE, 1380MM,(SEE FIG. K0711-01A0)
SN: 65001-UP
1шт.
11
AN51439-D0051
O-RING
SN: 65001-UP
2шт.
12
423-S62-4211
HOSE, 1040MM,(SEE FIG. C0110-04A0)
SN: 65001-UP
1шт.
13
AN51439-D0041
O-RING
SN: 65001-UP
2шт.
14
423-S62-4231
HOSE, 1960MM,(SEE FIG. K0711-01A0)
SN: 65001-UP
1шт.
15
AN51439-D0031
O-RING
SN: 65001-UP
2шт.
16
423-S62-4221
HOSE, 430MM,(SEE FIG. C0110-04A0)
SN: 65001-UP
1шт.
17
AN51439-D0031
O-RING
SN: 65001-UP
2шт.
18
423-07-31571
RECEIVER DRYER,(SEE FIG. C0110-04A0)
SN: 65001-UP
1шт.
19
423-S62-4330
COMPRESSOR ASS'Y,(SEE FIG. K0711-01A0)
SN: 65001-UP
1шт.
