Запчасти Komatsu WA380-6 C-A РАДИАТОР ВЕНТИЛЯТОР ОХЛАЖДЕНИЯ МОТОР (/) СИСТЕМА ОХЛАЖДЕНИЯ

|$0

MOTOR ASSEMBLY (SEE FIG. C0110-02A1)

SN: A53001--UP

-1шт.

1

07000-E2110

O-RING

SN: A53001--UP

1шт.

2

04020-00616

PIN, DOWEL

SN: A53001--UP

2шт.

3

01252-61255

BOLT

SN: A53001--UP

4шт.

4

708-7S-12330

SHAFT

SN: A53001--UP

1шт.

5

708-7S-12140

BEARING

SN: A53001--UP

1шт.

6

708-7S-12220

BEARING

SN: A53001--UP

1шт.

7

708-7S-05110

SHIM KIT

SN: A53001--UP

1шт.

8

708-7T-12330

SEAL, OIL

SN: A53001--UP

1шт.

9

708-1S-11890

SPACER

SN: A53001--UP

1шт.

10

04065-04518

RING, SNAP

SN: A53001--UP

1шт.

11

708-7S-13120

BLOCK, CYLINDER

SN: A53001--UP

1шт.

12

708-7S-13250

PLATE, VALVE

SN: A53001--UP

1шт.

13

720-68-19610

PIN

SN: A53001--UP

1шт.

14

708-2L-23360

PIN

SN: A53001--UP

3шт.

15

708-7S-13530

SPACER

SN: A53001--UP

2шт.

16

708-7S-13560

SPRING

SN: A53001--UP

1шт.

17

04065-03212

RING, SNAP

SN: A53001--UP

1шт.

18

708-7S-13550

GUIDE, RETAINER

SN: A53001--UP

1шт.

19

708-7S-13360

RETAINER, SHOE

SN: A53001--UP

1шт.

20

708-7S-13350

PISTON SUB ASSEMBLY

SN: A53001--UP

5шт.

21

708-7S-13420

PLATE, THRUST

SN: A53001--UP

1шт.

|$22

22

-1шт.

|$23

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

23

-1шт.
