Запчасти Komatsu WA380-6 H-A ГИДР. НАСОС. ГИДРОТРАНСФОРМАТОР ПОДАЧА ГИДРАВЛИКА

|$0

705-94-01070

PUMP, TORQUE CONVERTER CHARGE

SN: A54001--UP

1шт.

1

705-94-81010

BRACKET ASSEMBLY

SN: A54001--UP

1шт.

N/I

705-94-80620

BUSHING

SN: A54001--UP

2шт.

2

705-94-81310

CARRIER

SN: A54001--UP

1шт.

N/I

705-94-80610

BUSHING

SN: A54001--UP

2шт.

3

705-94-38021

CASE, GEAR

SN: A54001--UP

1шт.

4

705-94-38640

GEAR, DRIVE

SN: A54001--UP

1шт.

5

705-94-38510

GEAR, DRIVEN

SN: A54001--UP

1шт.

6

705-94-80721

PLATE, SIDE

SN: A54001--UP

1шт.

7

705-94-80711

PLATE, SIDE

SN: A54001--UP

1шт.

8

705-94-80770

SEAL

SN: A54001--UP

2шт.

9

04020-00820

PIN, DOWEL

SN: A54001--UP

4шт.

10

705-94-80820

SEAL, OIL

SN: A54001--UP

1шт.

11

04065-05820

RING, SNAP

SN: A54001--UP

1шт.

12

01253-61410

BOLT

SN: A54001--UP

4шт.

13

01643-31445

WASHER

SN: A54001--UP

4шт.

14

705-94-85020

BOLT

SN: A54001--UP

4шт.

15

01580-11411

NUT

SN: A54001--UP

4шт.

16

01643-31445

WASHER

SN: A54001--UP

4шт.

|$19

19

-1шт.

|$20

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

20

-1шт.
