Запчасти Komatsu WA40-3 ОСНОВН. НАСОС (ПОРШЕНЬ НАСОС ВНУТР. ЧАСТИ) (ПОВОРОТН. ГРУППА)(№97-8999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

363-17-31402

PUMP ASS'Y,(A4VG28DA-931-0)

SN: 14972-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-01A0E T0 Y1610-07A0B .

-1шт.

|$$3

THE UCHIDA YUATSU KIKI PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

UCBA041S9146-0

PUMP ASS'Y,PISTON

SN: 14972-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-02A0B T0 Y1610-06A0A .

-1шт.

|$6

UC4704375889

ROTARY ASS'Y

SN: 14972-UP

1шт.

1

UC4704354498

CYLINDER ASS'Y

SN: 14972-UP

1шт.

2

UC4704315415

PISTON ASS'Y

SN: 14972-UP

9шт.

3

UC4704355088

HANGER ASS'Y

SN: 14972-UP

1шт.

4

UC1704323552

SPRING

SN: 14972-UP

1шт.

5

UC1704152653

SHAFT

SN: 14972-UP

1шт.

6

UC1704198246

CASE,SEAL

SN: 14972-UP

1шт.

7

UC1704139201

PIN

SN: 14972-UP

2шт.

8

UC1704321419

RETAINER

SN: 14972-UP

1шт.

9

UC1704313427

GUIDE

SN: 14972-UP

1шт.

10

UC1706500494

GUIDE

SN: 14972-UP

1шт.

11

UC1100361998

PLATE,CONTROL

SN: 14972-UP

1шт.

12

UC1701566059

BEARING

SN: 14972-UP

1шт.

13

UC1701566251

BEARING

SN: 14972-UP

2шт.

14

04064-02512

RING,SNAP

SN: 14972-UP

1шт.

15

04065-06825

RING,SNAP

SN: 14972-UP

1шт.

16

UC1100354339

SEAL,OIL

SN: 14972-UP

1шт.

17

UC1300271009

O-RING

SN: 14972-UP

1шт.

18

UC1704350022

SHIM,0.6MM

SN: 14972-UP

1шт.

18

UC1100474589

SHIM,0.7MM

SN: 14972-UP

1шт.

18

UC1704350013

SHIM,0.8MM

SN: 14972-UP

1шт.

18

UC1100474599

SHIM,0.9MM

SN: 14972-UP

1шт.

18

UC1704350004

SHIM,1.0MM

SN: 14972-UP

1шт.

18

UC1100474609

SHIM,1.1MM

SN: 14972-UP

1шт.

18

UC1704329999

SHIM,1.2MM

SN: 14972-UP

1шт.
