Запчасти Komatsu WA400-3A РУКОЯТЬ И КОЛЕНЧАТЫЙ РЫЧАГ (С АВТОМАТИЧ. СМАЗКОЙ СИСТЕМА) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

424-S95-2620

LIFT ARM ASS'Y

SN: 53001-UP

1шт.

|1

424-875-1160

SEAT (WELDED)

SN: 53001-UP

2шт.

|1

421-S95-2322

PLATE (WELDED)

SN: 53001-UP

1шт.

|1

419-S95-2520

PLATE (WELDED)

SN: 53001-UP

2шт.

|1

419-S95-2530

PLATE (WELDED)

SN: 53001-UP

2шт.

|1

419-S95-2810

BLOCK (WELDED)

SN: 53001-UP

1шт.

|1

419-S95-2820

SEAT (WELDED)

SN: 53001-UP

2шт.

|1

01571-01016

SEAT (WELDED)

SN: 53001-UP

7шт.

|2

0

ARM,LIFT

SN: 53001-UP

1шт.

2

423-70-21810

BUSHING

SN: 53001-UP

2шт.

3

424-70-11770

BUSHING

SN: 53001-UP

2шт.

4

424-70-11890

BUSHING

SN: 53001-UP

2шт.

5

424-09-12320

SEAL,DUST

SN: 53001-UP

4шт.

6

421-09-11310

SEAL,DUST

SN: 53001-UP

8шт.

7

07020-00000

FITTING,GREASE

SN: 53001-UP

2шт.

|8

424-S95-2580

BELLCRANK ASS'Y

SN: 53001-UP

1шт.

|8

423-S95-2720

PLATE (WELDED)

SN: 53001-UP

1шт.

|8

423-S95-2780

PLATE (WELDED)

SN: 53001-UP

2шт.

|8

01571-01016

SEAT (WELDED)

SN: 53001-UP

3шт.

|8

01573-20205

SEAT (WELDED)

SN: 53001-UP

1шт.

|8

424-70-21200

BELLCRANK ASS'Y

SN: 53001-UP

1шт.

8

0

BELLCRANK

SN: 53001-UP

1шт.

9

424-70-11860

BUSHING

SN: 53001-UP

1шт.

10

421-09-11350

SEAL,DUST

SN: 53001-UP

2шт.

11

07020-00900

FITTING,GREASE

SN: 53001-UP

1шт.

|12

423-S95-3100

LINK ASS'Y

SN: 53001-UP

1шт.

|12

423-S95-3230

LINK ASS'Y

SN: 53001-UP

1шт.

12

423-70-21140

LINK

SN: 53001-UP

1шт.

|12

419-46-12E30

SEAT (WELDED)

SN: 53001-UP

2шт.

|12

01571-01016

SEAT (WELDED)

SN: 53001-UP

1шт.

13

423-S95-2910

BUSHING

SN: 53001-UP

1шт.

14

424-70-11820

BUSHING

SN: 53001-UP

1шт.

15

424-09-12320

SEAL,DUST

SN: 53001-UP

4шт.

16

07020-00000

FITTING,GREASE

SN: 53001-UP

2шт.

17

07000-15085

O-RING

SN: 53001-UP

2шт.
