1
424-877-1750
TUBE, L.H. - CONTROL VALVE TO BOOM HOSE
1шт.
|$1
07372-21035
BOLT - TUBE TO CONTROL VALVE
4шт.
|$2
01643-51032
WASHER
4шт.
2
424-877-1760
TUBE, R.H. - CONTROL VALVE TO BOOM HOSE
1шт.
|$4
07372-21035
BOLT - TUBE TO CONTROL VALVE
4шт.
|$5
01643-51032
WASHER
4шт.
3
07000-13035
RING, SEAL
2шт.
4
423-877-1212
ANGLE, CLAMP TUBE TO FRONT FRAME
2шт.
|$8
01435-01035
BOLT, ANGLE MOUNTING
4шт.
|$9
01584-01008
NUT
4шт.
5
07283-33450
U-BOLT, TUBE CLAMP
8шт.
|$11
01643-31032
WASHER
16шт.
|$12
01597-01009
NUT
16шт.
6
07283-53444
SEAT
8шт.
7
07125-01014
HOSE
2шт.
8
07000-13032
RING, SEALING
6шт.
9
07371-31049
FLANGE - SPLIT
12шт.
|$17
07372-21035
BOLT - SPLIT FLANGE MOUNTING
24шт.
|$18
01643-51032
WASHER
24шт.
10
07378-11000
HEAD
2шт.
11
424-877-1220
TUBE, L.H. - HOSE TO FRONT ATTACHMENT
1шт.
12
423-877-1150
BRACKET, R.H. BOTTOM - TUBE CLAMP U-BOLT
1шт.
|$22
01435-01220
BOLT, BRACKET MOUNTING
2шт.
13
423-877-1170
BRACKET, R.H. TOP - TUBE CLAMP U-BOLT
1шт.
|$24
01435-01220
BOLT, BRACKET MOUNTING
2шт.
14
423-877-1180
BRACKET, L.H. BOTTOM - TUBE CLAMP U-BOLT
1шт.
|$26
01435-01220
BOLT, BRACKET MOUNTING
2шт.
15
423-877-1160
BRACKET, L.H. TOP - TUBE CLAMP U-BOLT
1шт.
|$28
01435-01220
BOLT, BRACKET MOUNTING
2шт.
16
423-877-1330
BRACKET, TUBE - L.H
1шт.
N/I
423-877-1340
BRACKET, TUBE - R.H
1шт.
|$31
01435-01220
BOLT, BRACKET MOUNTING
4шт.
17
ARM, LIFT (SEE PG 07-002)
-29шт.
18
FRAME, FRONT (SEE PG 05-002)
-29шт.
19
COVER, ACCESS (SEE PG 05-002)
-29шт.
20
VALVE ASSEMBLY, THREE-SPOOL EQUIPMENT CONTROL
-1шт.
|$36
(SEE FIG. 6201A)
1шт.
21
424-877-1230
TUBE, R.H. - HOSE TO FRONT ATTACHMENT
1шт.
