|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$5
714-17-20003
TRANSMISSION ASS'Y
SN: (110604)-UP
1шт.
|$6
714-17-20002
TRANSMISSION ASS'Y
SN: 60001-(110603)
1шт.
|$7
0
TRANSMISSION ASS'Y
SN: (60001-(110185))
1шт.
|$8
0
TRANSMISSION ASS'Y
SN: (60001-(110179))
1шт.
|$9
714-17-20303
TRANSMISSION ASS'Y
SN: (110604)-UP
1шт.
|$10
714-17-20302
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: 60001-(110603)
1шт.
|$11
0
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: (60001-(110185))
1шт.
|$12
0
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: (60001-(110179))
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
|$21
714-12-22010
CLUTCH ASS'Y,FORWARD AND REVERSE
SN: 60001-UP
1шт.
1
714-12-22111
SHAFT AND CYLINDER A
SN: 60001-UP
1шт.
1
0
SHAFT,INPUT
SN: 60001-UP
1шт.
1
0
PLUG
SN: (110592)-UP
2шт.
1
0
SCREW
SN: 60001-(110591)
2шт.
1
0
ORIFICE
SN: 60001-UP
1шт.
1
0
HOUSING
SN: 60001-UP
1шт.
2
714-07-22652
PISTON,FOWARD AND REVERSE
SN: 60001-UP
2шт.
3
714-07-29720
DISC
SN: 60001-UP
24шт.
4
714-16-19730
PLATE,SEPARATE
SN: 60001-UP
26шт.
5
56D-15-12710
SPRING,WAVE
SN: (110039)-UP
24шт.
5
0
SPRING,WAVE
SN: 60001-(110038)
24шт.
6
714-07-22720
PLATE
SN: 60001-UP
2шт.
7
714-07-22610
PLATE,END
SN: 60001-UP
2шт.
8
419-15-12140
RING,SNAP
SN: 60001-UP
2шт.
9
714-11-19230
RING,SEAL (K1)
SN: 60001-UP
2шт.
10
714-16-19210
RING,SEAL (K1)
SN: 60001-UP
2шт.
11
714-08-19570
WASHER,THRUST
SN: 60001-UP
4шт.
12
714-23-19430
BEARING,NEEDLE
SN: 60001-UP
3шт.
13
714-11-12720
SPACER
SN: 60001-UP
1шт.
14
714-07-22711
SPACER
SN: 60001-UP
1шт.
15
714-12-19380
BEARING
SN: 60001-UP
2шт.
16
714-12-22421
GEAR, 40 TEETH,FORWARD
SN: 60001-UP
1шт.
17
714-12-22411
GEAR, 31 TEETH,REVERSE
SN: 60001-UP
1шт.
18
714-19-19210
RING,SEAL (K1)
SN: 60001-UP
4шт.
