|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$3
714-17-20313
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (110604)-UP
1шт.
|$4
714-17-20312
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: 60001-(110603)
1шт.
|$5
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (60001-(110185))
1шт.
|$6
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (60001-(110179))
1шт.
|$$6
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A1.
-1шт.
|$10
714-12-25013
VALVE ASS'Y
SN: 60001-UP
1шт.
|$11
0
VALVE ASS'Y
SN: (60001-60079)
1шт.
|$$9
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-59A1 AND F4350-60A0.
-1шт.
1
714-12-25132
VALVE SEAT
SN: 60001-UP
1шт.
2
07043-70108
PLUG
SN: 60001-UP
3шт.
3
07043-70211
PLUG
SN: 60001-UP
15шт.
4
07043-70312
PLUG
SN: 60001-UP
2шт.
5
714-12-25503
ECMV ASS'Y
SN: (110629)-UP
7шт.
5
714-12-25700
ECMV ASS'Y
SN: (110587)-(110628)
7шт.
5
714-12-25500
ECMV ASS'Y
SN: 60001-(110586)
7шт.
6
07000-72015
O-RING (K2)
SN: 60001-UP
28шт.
7
07000-71007
O-RING (K2)
SN: 60001-UP
7шт.
8
01252-70650
BOLT
SN: 60001-UP
28шт.
9
04260-01270
BALL
SN: 60001-UP
1шт.
10
234-15-15120
SPRING
SN: 60001-UP
1шт.
11
714-10-16890
PLUG
SN: 60001-UP
1шт.
12
07002-12034
O-RING (K2)
SN: 60001-UP
1шт.
|$27
714-12-25200
SOLENOID VALVE ASS'Y
SN: (110054)-UP
1шт.
|$28
0
SOLENOID VALVE ASS'Y
SN: ((110054)-(110076))
1шт.
|$29
0
SOLENOID VALVE ASS'Y
SN: 60001-(110053)
1шт.
13
714-12-25220
SOLENOID VALVE
SN: (110065)-UP
1шт.
13A
0
BLOCK
SN: (110065)-UP
1шт.
14
0
BLOCK
SN: (60001-(110076))
1шт.
15
07043-70108
PLUG
SN: 60001-UP
1шт.
16
07042-80108
PLUG
SN: 60001-UP
1шт.
17
07000-72012
O-RING (K2)
SN: 60001-UP
3шт.
18
01010-81070
BOLT
SN: 60001-UP
1шт.
19
01643-31032
WASHER
SN: 60001-UP
1шт.
20
08193-21012
CLIP
SN: 60001-UP
2шт.
21
01435-01016
BOLT
SN: 60001-UP
2шт.
22
569-15-51721
FILTER ASS'Y
SN: (110629)-UP
1шт.
22
569-15-51720
FILTER ASS'Y
SN: (110604)-(110628)
1шт.
22
714-23-11720
FILTER
SN: 60001-(110603)
1шт.
22
569-15-51732
ELEMENT ASS'Y
SN: (110629)-UP
1шт.
22
569-15-51731
ELEMENT ASS'Y
SN: (110604)-(110628)
1шт.
22
714-23-11730
ELEMENT ASS'Y
SN: 60001-(110603)
1шт.
22
07000-02060
O-RING
SN: 60001-UP
1шт.
23
07040-11812
PLUG
SN: 60001-UP
1шт.
24
07002-11823
O-RING (K2)
SN: 60001-UP
1шт.
25
07000-73022
O-RING (K2)
SN: 60001-UP
2шт.
26
01010-81030
BOLT
SN: 60001-UP
1шт.
27
01010-81080
BOLT
SN: 60001-UP
1шт.
28
01643-31032
WASHER
SN: 60001-UP
2шт.
29
0
PLATE, NAME,(LIMITED SUPPLY)
SN: 60001-UP
1шт.
30
714-07-26000
VALVE ASS'Y
SN: 60001-UP
1шт.
31
07000-73030
O-RING (K2)
SN: 60001-UP
5шт.
32
01010-81065
BOLT
SN: 60001-UP
2шт.
33
01643-31032
WASHER
SN: 60001-UP
2шт.
34
07043-A0108
PLUG
SN: 60001-UP
1шт.
35
714-23-15690
BRACKET
SN: 60001-UP
1шт.
36
01252-60510
BOLT
SN: 60001-UP
2шт.
