|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$5
714-17-20013
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: (110604)-UP
1шт.
|$6
714-17-20012
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: 60001-(110603)
1шт.
|$7
0
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: (60001-(110185))
1шт.
|$8
0
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: (60001-(110179))
1шт.
|$9
714-17-20313
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (110604)-UP
1шт.
|$10
714-17-20312
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: 60001-(110603)
1шт.
|$11
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (60001-(110185))
1шт.
|$12
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (60001-(110179))
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A1.
-1шт.
|$14
711-49-51010
T.WA430-5
SN: 60001-UP
1шт.
1
01010-80825
BOLT
SN: 60001-UP
24шт.
2
01643-30823
WASHER
SN: 60001-UP
24шт.
3
711-49-62550
SHAFT
SN: (110562)-UP
1шт.
3
711-47-52550
SHAFT
SN: 60001-(110561)
1шт.
4
07018-31205
RING,SEAL (K1)
SN: 60001-UP
1шт.
5
04077-00120
RING,SNAP
SN: 60001-UP
2шт.
6
714-12-25503
ECMV ASS'Y
SN: (110562)-UP
7шт.
6
711-47-51160
BEARING
SN: 60001-(110561)
1шт.
7
711-47-52680
NUT
SN: 60001-UP
1шт.
8
711-47-52140
BUSHING
SN: 60001-UP
2шт.
9
711-47-52160
WHEEL
SN: 60001-UP
1шт.
10
711-47-52120
OUTER RACE
SN: 60001-UP
1шт.
11
01010-81060
BOLT
SN: 60001-UP
12шт.
12
01643-31032
WASHER
SN: 60001-UP
12шт.
13
711-47-51191
GUIDE
SN: 60001-UP
1шт.
14
711-49-51411
PUMP
SN: 60001-UP
1шт.
15
711-50-51520
TURBINE
SN: 60001-UP
1шт.
16
711-47-51570
BOSS
SN: 60001-UP
1шт.
17
01010-81025
BOLT
SN: 60001-UP
18шт.
18
01643-31032
WASHER
SN: 60001-UP
18шт.
19
711-50-51430
STATOR
SN: 60001-UP
1шт.
20
04260-00635
BALL
SN: 60001-UP
2шт.
21
06040-06214
BEARING
SN: 60001-UP
1шт.
22
711-47-11770
PLATE
SN: 60001-UP
1шт.
23
04064-07025
RING,SNAP
SN: 60001-UP
1шт.
24
01010-81035
BOLT
SN: 60001-UP
8шт.
25
01643-31032
WASHER
SN: 60001-UP
8шт.
26
711-50-57210
CASE
SN: 60001-UP
1шт.
27
711-50-57110
HOUSING, COMPLETE
SN: 60001-UP
1шт.
28
23S-13-47210
PISTON
SN: 60001-UP
1шт.
29
711-35-17151
RING,SEAL
SN: 60001-UP
1шт.
30
568-15-12850
RING,SEAL (K1)
SN: 60001-UP
2шт.
31
424-15-12711
DISC
SN: 60001-UP
1шт.
32
01010-80860
BOLT
SN: 60001-UP
24шт.
33
01643-30823
WASHER
SN: 60001-UP
24шт.
34
711-47-51280
PILOT
SN: (110562)-UP
1шт.
34
711-50-51270
PILOT
SN: 60001-(110561)
1шт.
35
711-47-51151
GEAR, 97 TEETH
SN: 60001-UP
1шт.
