|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-17-20000
TRANSMISSION ASS'Y,(STD)
SN: 60001-UP
1шт.
|1
714-17-20010
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 60001-UP
1шт.
|1
714-17-20100
TRANSMISSION ASS'Y,(FOR TACHOGRAPH)
SN: 60001-UP
1шт.
|1
714-17-20110
TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND LOCK-UP)
SN: 60001-UP
1шт.
|1
714-17-20300
TRANSMISSION ASS'Y,(COLD TERRAIN SPEC.)
SN: 60001-UP
1шт.
|1
714-17-20310
TRANSMISSION ASS'Y,(WITH LOCK-UP) (COLD)
SN: 60001-UP
1шт.
|1
714-17-20400
TRANSMISSION ASS'Y,(FOR TACHOGRAPH) (COLD)
SN: 60001-UP
1шт.
|1
714-17-20410
TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND L/C) (C)
SN: 60001-UP
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
1
714-12-24520
SHAFT,OUTPUT
SN: 60001-UP
1шт.
2
714-12-24620
GEAR,OUTPUT
SN: 60001-UP
1шт.
3
06002-32215
BEARING
SN: 60001-UP
1шт.
4
06002-32017
BEARING
SN: 60001-UP
1шт.
5
714-12-23830
SPACER
SN: 60001-UP
1шт.
6
714-07-28611
HUB,SPLINE
SN: 60001-UP
1шт.
7
714-12-27141
CAGE
SN: 60001-UP
1шт.
8
07012-50095
SEAL
SN: 60001-UP
2шт.
9
425-15-28710
SEAL,DUST (K1)
SN: 60001-UP
2шт.
10
07000-15140
O-RING (K1)
SN: 60001-UP
1шт.
11
01010-81235
BOLT
SN: 60001-UP
6шт.
12
714-12-27111
HOUSING
SN: 60001-UP
1шт.
13
714-12-27121
HOUSING
SN: 60001-UP
1шт.
14
07000-15275
O-RING (K1)
SN: 60001-UP
1шт.
15
01016-51250
BOLT
SN: 60001-UP
3шт.
16
07043-A0312
PLUG
SN: 60001-UP
2шт.
17
714-07-27161
SPRING
SN: 60001-UP
10шт.
18
714-07-27151
SPRING
SN: 60001-UP
10шт.
19
714-12-27131
PISTON
SN: 60001-UP
1шт.
20
07000-A6210
O-RING (K1)
SN: 60001-UP
1шт.
21
07000-A6260
O-RING (K1)
SN: 60001-UP
1шт.
22
07001-06265
RING
SN: 60001-UP
1шт.
23
04020-01842
PIN
SN: 60001-UP
2шт.
24
714-07-12670
DISC
SN: 60001-UP
9шт.
25
714-12-19730
PLATE,SEPARATE
SN: 60001-UP
10шт.
26
714-07-12691
SPRING,WAVE
SN: (110039)-UP
9шт.
|26
0
SPRING,WAVE
SN: 60001-(110038)
9шт.
27
714-12-17250
PLATE,END
SN: 60001-UP
1шт.
28
714-07-12720
RING,SNAP
SN: 60001-UP
2шт.
29
714-12-24271
SHIM¤ 0.05MM (K1)
SN: 60001-UP
6шт.
|29
714-12-24281
SHIM¤ 0.5MM (K1)
SN: 60001-UP
4шт.
|29
714-12-24291
SHIM¤ 0.2MM (K1)
SN: 60001-UP
4шт.
30
714-17-24111
COUPLING
SN: 60001-UP
1шт.
|30
0
COUPLING
SN: 60001-UP
1шт.
|30
0
COVER
SN: 60001-UP
1шт.
31
772-14-13130
HOLDER
SN: 60001-UP
1шт.
32
07000-15060
O-RING (K1)
SN: 60001-UP
1шт.
33
01011-62020
BOLT
SN: 60001-UP
1шт.
34
01643-32060
WASHER
SN: 60001-UP
1шт.
35
714-12-24120
COUPLING
SN: 60001-UP
1шт.
|35
0
COUPLING
SN: 60001-UP
1шт.
|35
0
COUPLING,REAR
SN: 60001-UP
1шт.
|35
0
COVER
SN: 60001-UP
1шт.
|35
0
DEFLECTOR
SN: 60001-UP
1шт.
