|1
714-17-20000
TRANSMISSION ASS'Y,(STD)
SN: 60001-UP
1шт.
|1
714-17-20010
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 60001-UP
1шт.
|1
714-17-20100
TRANSMISSION ASS'Y,(FOR TACHOGRAPH)
SN: 60001-UP
1шт.
|1
714-17-20110
TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND LOCK-UP)
SN: 60001-UP
1шт.
|1
714-17-20300
TRANSMISSION ASS'Y,(COLD TERRAIN SPEC.)
SN: 60001-UP
1шт.
|1
714-17-20310
TRANSMISSION ASS'Y,(WITH LOCK-UP) (COLD)
SN: 60001-UP
1шт.
|1
714-17-20400
TRANSMISSION ASS'Y,(FOR TACHOGRAPH) (COLD)
SN: 60001-UP
1шт.
|1
714-17-20410
TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND L/C) (C)
SN: 60001-UP
1шт.
|$$9
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
1
714-12-28111
CASE,FRONT
SN: 60001-UP
1шт.
|2
714-12-21122
CASE,REAR
SN: 60001-UP
1шт.
2
714-12-28122
CASE,REAR
SN: 60001-UP
1шт.
3
07043-70617
PLUG
SN: 60001-UP
4шт.
4
07043-70415
PLUG
SN: 60001-UP
1шт.
5
07043-70312
PLUG
SN: 60001-UP
1шт.
6
07043-70211
PLUG
SN: 60001-UP
1шт.
7
04020-01228
PIN,DOWEL
SN: 60001-UP
2шт.
8
01010-81240
BOLT
SN: 60001-UP
20шт.
9
01010-81270
BOLT
SN: 60001-UP
6шт.
10
01643-51232
WASHER
SN: 60001-UP
6шт.
11
07000-15285
O-RING (K1)
SN: 60001-UP
1шт.
12
01011-81205
BOLT
SN: 60001-UP
7шт.
13
01011-81210
BOLT
SN: 60001-UP
2шт.
14
01643-31232
WASHER
SN: 60001-UP
2шт.
15
714-07-28141
CAGE
SN: 60001-UP
1шт.
16
714-07-28211
SHIM¤ 0.05MM (K1)
SN: 60001-UP
6шт.
|16
714-07-28221
SHIM¤ 0.5MM (K1)
SN: 60001-UP
4шт.
|16
714-07-28231
SHIM¤ 0.2MM (K1)
SN: 60001-UP
4шт.
17
07000-15130
O-RING (K1)
SN: 60001-UP
1шт.
18
01010-81235
BOLT
SN: 60001-UP
6шт.
19
714-12-24910
COVER,GEAR
SN: 60001-UP
1шт.
20
01011-81200
BOLT
SN: 60001-UP
3шт.
21
01643-31232
WASHER
SN: 60001-UP
3шт.
22
419-15-18131
LIQUID GASKET,(NOT SHOWN) (K1)
SN: 60001-UP
1шт.
