Запчасти Komatsu WA430-6 A9-AA ТОПЛИВН. ФИЛЬТР. ДВИГАТЕЛЬ

1

6732-22-3110

BOLT (M10-1.50x35)

2шт.

2

6731-61-4250

BOLT (M10-1.50x25)

2шт.

3

6745-71-6230

BRACE, FILTER

1шт.

4

6745-71-6210

SUPPORT, FILTER

1шт.

|$4

6732-21-1960

PLUG, THREADED

3шт.

5

NSS

PLUG, THREADED

1шт.

6

6215-81-9710

SEAL, O-RING

1шт.

7

600-411-1191

CORROSION RESISTOR

1шт.

|$18

OR

8

-1шт.

8

600-411-9000

COVER

1шт.

9

6745-71-1130

WASHER, SEALING

2шт.

10

6745-71-6130

CONNECTION, ADAPTER

2шт.

11

6754-71-6330

ADAPTER, FILTER HEAD

2шт.

12

6745-71-6150

HEAD, FUEL FILTER

1шт.

13

6754-71-6140

FILTER, FUEL

1шт.

14

6732-11-4170

BOLT (M8-1.25x90)

5шт.

15

6745-71-5830

COVER, PROTECTIVE

1шт.

16

6745-71-6160

ADAPTER, CORROSION RESISTOR

1шт.

|$19

18

-1шт.

|$20

F2 - COVER IS USED IN PLACE OF CORROSION RESISTOR WHEN USING RECOMMENDED KOMATSU SUPERCOOLANT.

20

-1шт.

|$21

F2 - COVER IS USED IN PLACE OF CORROSION RESISTOR WHEN USING RECOMMENDED KOMATSU SUPERCOOLANT.

20

-1шт.
