1
UNIT ASSEMBLY, AIR CONDITIONER (SEE PG 05-148)
a
-29шт.
1
UNIT ASSEMBLY, AIR CONDITIONER (SEE PG 05-152)
b
-29шт.
1
UNIT ASSEMBLY, HEATER (SEE PG 05-166)
c
-29шт.
1
UNIT ASSEMBLY, HEATER (SEE PG 05-168)
d
-29шт.
2
01435-01220
BOLT, AIR CONDITIONER MOUNTING
3шт.
3
07049-01215
PLUG
2шт.
4
421-T43-1212
BOX ASSEMBLY
a
1шт.
4
BOX ASSEMBLY (SEE PG 05-138)
b
-29шт.
5
423-963-1330
INSULATOR
2шт.
6
423-963-1310
INSULATOR
2шт.
7
01435-01220
BOLT, BOX MOUNTING
a
7шт.
7
01435-00820
BOLT, FILTER BOX MOUNTING
b
3шт.
8
421-07-12312
FILTER, AIR
2шт.
9
425-07-11130
PLATE
1шт.
10
01540-20840
NUT
1шт.
11
425-963-1210
BRACKET, BLOWER MOUNTING
1шт.
12
BLOWER ASSEMBLY (SEE PG 05-176)
-29шт.
13
01435-00820
BOLT, BLOWER MOUNTING
4шт.
14
425-963-1180
DUCT, AIR
1шт.
15
425-963-1170
DAMPER ASSEMBLY
1шт.
16
01435-00820
BOLT, DAMPER MOUNTING
2шт.
17
01643-30823
WASHER, DAMPER MOUNTING
2шт.
18
01580-10806
NUT, DAMPER MOUNTING
2шт.
19
421-T43-1390
COVER, BOX ASSEMBLY
1шт.
20
423-T43-1430
FILTER, INNER
2шт.
21
01435-00816
BOLT, FILTER MOUNTING
2шт.
22
01220-40820
SCREW, FILTER MOUNTING
2шт.
23
01643-30823
WASHER
6шт.
24
01580-10806
NUT
2шт.
25
421-T43-1340
PLATE
2шт.
26
421-T43-1330
PLATE
2шт.
27
01435-00616
BOLT
4шт.
28
425-54-12960
SCREW
2шт.
29
01643-30623
WASHER
2шт.
30
08037-02512
GROMMET
1шт.
31
421-07-12512
GRILLE
2шт.
32
423-07-11110
INSULATOR
1шт.
|$46
-1шт.
|$38
F1 - USED ON MACHINES S/N A25001 THRU A25485 AND S/N A25487
-1шт.
|$39
THRU A25514.
-1шт.
|$47
-1шт.
|$41
F2 - USED ON MACHINES S/N A25486 AND A25515 AND UP.
-1шт.
|$48
-1шт.
|$49
-1шт.
|$44
F3 - BOX ASSEMBLY P/N 423-963-A010 USES SEVEN (7) MOUNT BOLTS,
-1шт.
|$45
WHILE BOX ASSEMBLY P/N 421-T43-1212 USES FOUR (4) MOUNT BOLTS.
-1шт.
