1
VALVE, TWO-SPOOL (SEE PG 06-020)
-29шт.
2
07000-13045
O-RING
2шт.
3
421-S99-1440
TUBE (E.C.S.S.)
1шт.
N/I
07000-12032
O-RING
2шт.
4
07283-33450
CLIP
4шт.
5
421-S99-1430
TUBE (E.C.S.S.)
1шт.
N/I
07000-12032
O-RING
2шт.
6
07235-50522
ELBOW
2шт.
7
07002-12434
O-RING
2шт.
8
421-S99-1450
TUBE
1шт.
9
07000-12060
O-RING
1шт.
10
07000-13048
O-RING
1шт.
11
07235-50522
ELBOW
2шт.
N/I
07042-30108
PLUG
2шт.
12
07002-12434
O-RING
6шт.
13
07102-20504
HOSE, RETURN TO VALVE
1шт.
14
07123-00505
HOSE, BOOM TO VALVE
2шт.
15
07230-10522
UNION
4шт.
16
421-S99-1131
E.C.S.S. VALVE
1шт.
|$19
01011-51225
BOLT
2шт.
|$20
01643-31232
WASHER
2шт.
17
421-S99-1390
BRACKET, E.C.S.S. VALVE
1шт.
|$22
01435-01225
BOLT, BRACKET
2шт.
18
07123-00508
HOSE, LOW PRESSURE ACCUMULATOR TO VALVE
1шт.
19
07235-50522
ELBOW
1шт.
N/I
07042-30108
PLUG
1шт.
N/I
07002-12434
O-RING
1шт.
20
721-07-12120
ACCUMULATOR, LOW PRESSURE
1шт.
21
01010-81230
BOLT, LOW PRESSURE ACCUMULATOR
2шт.
22
01643-31232
WASHER, LOW PRESSURE ACCUMULATOR
2шт.
23
421-S99-1340
BRACKET, LOW PRESSURE ACCUMULATOR MOUNTING
1шт.
24
421-S99-1351
CLIP, LOW PRESSURE ACCUMULATOR
1шт.
N/I
01643-31232
WASHER, LOW PRESSURE ACCUMULATOR CLIP
2шт.
25
426-43-19150
LOCK NUT, LOW PRESSURE ACCUMULATOR CLIP
2шт.
26
421-S99-1461
HOSE, HIGH PRESSURE ACCUMULATOR TO VALVE
1шт.
N/I
07283-33442
CLIP, MOUNTING TO S/T PIPING
1шт.
N/I
421-62-18530
PLATE, BACK-SUPPORT FOR CLIP
1шт.
N/I
04434-53411
CLIP, HOSE TO S/T PIPING
1шт.
N/I
07095-20523
CUSHION
1шт.
N/I
01643-31032
WASHER
2шт.
N/I
426-09-11160
LOCK WASHER
2шт.
27
07235-50522
ELBOW
1шт.
N/I
07042-30108
PLUG
1шт.
N/I
07002-12434
O-RING
1шт.
28
721-07-12510
ACCUMULATOR, HIGH PRESSURE
1шт.
29
421-S99-1380
BRACKET, LOWER MOUNTING FOR ACCUMULATOR
1шт.
N/I
01435-01225
BOLT, LOWER MOUNTING BRACKET
4шт.
30
421-S99-1350
CLIP, HIGH PRESSURE ACCUMULATOR
1шт.
N/I
01643-21232
WASHER
2шт.
N/I
426-43-19150
LOCK NUT
2шт.
31
421-S99-1370
BRACKET, UPPER MOUNTING FOR ACCUMULATOR
1шт.
N/I
01435-01225
BOLT, UPPER MOUNTING BRACKET
2шт.
32
01643-31232
WASHER, ACCUMULATOR TO UPPER MOUNTING BRACKET
2шт.
33
01010-81230
BOLT, ACCUMULATOR TO UPPER MOUNTING BRACKET
2шт.
