1
421-06-13422
SUPPORT, L.H
1шт.
2
421-06-13322
SUPPORT, R.H
1шт.
3
01435-01225
BOLT
6шт.
4
419-06-13221
BRACKET, L.H
1шт.
5
419-06-13231
BRACKET, R.H
1шт.
6
01010-81225
BOLT
6шт.
|$6
01643-31232
WASHER
6шт.
7
08037-03614
GROMMET
2шт.
8
LIGHT ASSEMBLY, FRONT DRIVING (SEE PG 01-062)
-29шт.
9
419-06-13250
COVER
2шт.
10
01010-80612
BOLT
8шт.
11
01643-30623
WASHER
8шт.
12
LIGHT ASSEMBLY, L.H. TURN SIGNAL AND PARKING
-1шт.
|$13
(SEE PG 01-064)
1шт.
13
LIGHT ASSEMBLY, R.H. TURN SIGNAL AND PARKING
-1шт.
|$15
(SEE PG 01-066)
1шт.
14
01220-40516
SCREW
8шт.
15
01601-20513
WASHER, SPRING
8шт.
16
421-06-12360
HARNESS, WIRING
2шт.
|$19
421-09-11150
CONNECTOR - AT FRONT DRIVING LIGHT
1шт.
|$20
421-09-11250
TERMINAL - AT FRONT DRIVING LIGHT
3шт.
|$21
421-09-11530
CONNECTOR - AT FRONT HARNESS - 3 TERMINAL TYPE
1шт.
|$22
421-09-11540
CONNECTOR - AT FRONT HARNESS - 4 TERMINAL TYPE
1шт.
|$23
421-09-11550
TERMINAL - AT FRONT HARNESS
7шт.
|$24
08021-00400
CONNECTOR - AT GROUND CONNECTION
1шт.
|$25
08022-04001
CONNECTOR - AT TURN SIGNAL AND PARKING LIGHT
3шт.
17
08036-11210
CLIP
2шт.
18
01010-81016
BOLT
2шт.
19
01643-31032
WASHER
2шт.
20
419-06-13241
COVER
2шт.
21
01010-80612
BOLT
12шт.
22
01643-30623
WASHER
12шт.
|$35
-1шт.
|$33
F1 - IF REPLACING BOLT, ORDER PART NUMBER 01435-00610.
-1шт.
|$34
WASHER 01643-30623 IS NOT REQUIRED WITH NEW BOLT.
-1шт.
