|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-07-10050
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 53001-54000
1шт.
|$$3
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.
-1шт.
|1
714-07-17014
VALVE ASS'Y,TRANSMISSION
SN: (106844)-(107071)
1шт.
|1
0
VALVE ASS'Y,TRANSMISSION
SN: 53001-(106843)
1шт.
|$$6
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0 TO F4350-63A0.
-1шт.
|1
714-07-17200
VALVE ASS'Y,LOWER
SN: 53001-54000
1шт.
1
0
BODY,LOWER VALVE
SN: 53001-@
1шт.
2
714-07-16250
VALVE,PRIORITY
SN: 53001-@
1шт.
3
714-07-16311
VALVE,F-R
SN: 53001-54000
1шт.
4
714-07-16321
VALVE,H-L
SN: 53001-54000
1шт.
5
714-07-16331
VALVE,SPEED
SN: 53001-@
1шт.
6
714-07-16340
VALVE,BRAKE
SN: 53001-@
1шт.
7
714-07-16620
SLEEVE
SN: 53001-@
2шт.
8
02720-10104
PLUG
SN: 53001-54000
3шт.
9
714-07-16570
PLUG
SN: 53001-@
2шт.
10
04260-00635
BALL,CHECK VALVE
SN: 53001-@
2шт.
11
714-07-16590
SPRING,CHECK VALVE
SN: 53001-@
2шт.
12
419-15-16631
SPACER
SN: 53001-@
2шт.
13
714-07-16260
SPRING,PRIORITY VALVE
SN: 53001-@
1шт.
14
714-07-16370
SPRING,F-R VALVE
SN: 53001-@
2шт.
15
419-15-16620
SPRING,H-L AND SPEED VALVE
SN: 53001-@
2шт.
16
714-07-16380
SPRING,BRAKE VALVE
SN: 53001-@
1шт.
17
714-07-16270
STOPPER
SN: 53001-@
1шт.
18
419-15-15640
PLUG
SN: 53001-@
3шт.
19
714-07-16842
COVER,LOWER VALVE¤ L.H.
SN: 53001-@
1шт.
20
714-07-16851
COVER,LOWER VALVE¤ R.H.
SN: 53001-@
1шт.
21
714-07-16950
GASKET,LOWER VALVE¤ L.H. (K2)
SN: 53001-@
1шт.
22
714-07-16960
GASKET,LOWER VALVE¤ R.H. (K2)
SN: 53001-@
1шт.
23
17A-15-17271
SOLENOID VALVE
SN: 53001-@
4шт.
|23
0
VALVE ASS'Y,SOLENOID
SN: (53001-(106492))
4шт.
24
714-10-16960
O-RING (K2)
SN: 53001-(106492)
1шт.
25
714-10-16970
O-RING (K2)
SN: 53001-(106492)
1шт.
26
714-07-16730
VALVE ASS'Y,SOLENOID
SN: 53001-@
1шт.
27
421-06-16510
O-RING (K2)
SN: 53001-@
1шт.
28
421-06-16520
O-RING (K2)
SN: 53001-@
1шт.
29
01220-40412
SCREW
SN: 53001-@
16шт.
30
01220-40416
SCREW
SN: 53001-@
4шт.
31
419-15-15640
PLUG
SN: 53001-54000
1шт.
32
415-15-15470
PLUG
SN: 53001-54000
1шт.
33
01010-80835
BOLT
SN: 53001-@
7шт.
34
01252-40845
BOLT
SN: 53001-@
2шт.
35
01252-40835
BOLT
SN: 53001-@
12шт.
36
01252-40825
BOLT
SN: 53001-@
2шт.
37
07042-30108
PLUG
SN: 53001-@
2шт.
