1
VALVE ASSEMBLY, STEERING(SEE FIG. H0122-06A0)
SN: A31001-UP-UP
-1шт.
2
07102-20320
HOSE
SN: A31001-UP-UP
1шт.
3
08036-01814
CLIP
SN: A31001-UP-UP
1шт.
4
306 132 C1
BAND
SN: A31001-UP-UP
1шт.
5
07260-21480
HOSE
SN: A31001-UP-UP
1шт.
6
07281-00259
CLAMP
SN: A31001-UP-UP
2шт.
7
425-35-11650
NIPPLE
SN: A31001-UP-UP
1шт.
8
415-62-11550
NIPPLE
SN: A31001-UP-UP
3шт.
9
415-62-11560
O-RING
SN: A31001-UP-UP
4шт.
10
421-62-11960
NIPPLE
SN: A31001-UP-UP
1шт.
11
427-43-11370
BRACKET
SN: A31231-UP-UP
1шт.
12
BOLT (SEE FIG. H4410-05A0)
SN: A31001-UP-UP
-1шт.
13
ELBOW (SEE FIG. K4460-09A0)
SN: A31001-UP-UP
-1шт.
14
CLIP (SEE FIG. H4410-05A0)
SN: A31001-UP-UP
-1шт.
15
CLIP (SEE FIG. H4410-05A0)
SN: A31001-UP-UP
-1шт.
16
O-RING (SEE FIG. H4410-04A0)
SN: A31001-UP-UP
-1шт.
17
TEE (SEE FIG. H4410-04A0)
SN: A31001-UP-UP
-1шт.
18
NIPPLE (SEE FIG. H4410-04A0)
SN: A31001-UP-UP
-1шт.
