Запчасти Komatsu WA450-3MC FIG. J-A ПЕРЕДН. РАМА ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

1

421-46-A2401

FRAME, FRONT

SN: A31001-UP-UP

1шт.

|$2

OR

-1шт.

1

421-S99-A220

FRAME, FRONT - E.C.S.S.

SN: A31001-UP-UP

1шт.

2

NSS

PLATE, NAME - PRODUCT ID

SN: A31001-UP-UP

1шт.

3

04418-13060

SCREW

SN: A31001-UP-UP

4шт.

|$7

-1шт.

|$8

F1 - THIS PART MUST BE MODIFIED BY ADDING A MOUNTING BLOCKP/N 417-879-A251 ACCORDING TO P/N 421-879-A160 FRONT FRAMEREWORK DRAWING ON MACHINES WITH JRB 2 OR 3-SPOOL ATTACHMENT.CONTACT TAC FOR REWORK DRAWING.

-1шт.

|$9

-1шт.
