/ / / / / / FIG. K7-A БЛОК КОНДИЦИОНЕРА
Запчасти Komatsu WA450-3MC FIG. K7-A БЛОК КОНДИЦИОНЕРА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
3
32
37
2
18
29
34
22
23
21
8
4
12
15
9
33
31
6
25
27
26
43
31
33
19
5
33
25
33
24
38
13
38
33
7
30
42
25
28
37
17
14
31
1
33
39
10
16
27
40
45
41
11
35
36
20
44
|$0
425-07-21111
AIR CONDITIONER UNIT
SN: A31001-UP-UP
1шт.
1
ND245420-4200
CASE ASSEMBLY
SN: A31001-UP-UP
1шт.
2
ND245420-0210
CASE ASSEMBLY
SN: A31001-UP-UP
1шт.
3
ND116452-0561
CASE, HEATER
SN: A31001-UP-UP
1шт.
4
ND447600-0651
EVAPORATOR
SN: A31001-UP-UP
1шт.
|$5
ND949142-0030
0-RING
SN: A31001-UP-UP
1шт.
5
ND116410-9680
UNIT ASSEMBLY
SN: A31001-UP-UP
1шт.
6
ND447500-1030
VALVE, EXPANSION
SN: A31001-UP-UP
1шт.
7
ND113600-9260
VALVE ASSEMBLY, WATER
SN: A31001-UP-UP
1шт.
8
ND146622-6880
PACKING
SN: A31001-UP-UP
1шт.
9
ND116730-0530
DAMPER ASSEMBLY
SN: A31001-UP-UP
1шт.
10
ND116730-0520
DAMPER ASSEMBLY
SN: A31001-UP-UP
1шт.
11
ND017732-3041
LEVER, CONTROL
SN: A31001-UP-UP
1шт.
12
ND017732-3050
LEVER, CONTROL
SN: A31001-UP-UP
1шт.
13
ND017732-3060
LEVER, CONTROL
SN: A31001-UP-UP
1шт.
14
ND116662-0581
SHAFT
SN: A31001-UP-UP
1шт.
15
ND116662-0590
SHAFT
SN: A31001-UP-UP
1шт.
16
ND116427-5540
PIPE
SN: A31001-UP-UP
1шт.
17
ND116427-2320
PIPE
SN: A31001-UP-UP
1шт.
18
ND017660-3490
BRACKET
SN: A31001-UP-UP
2шт.
19
ND446870-2320
TUBE
SN: A31001-UP-UP
1шт.
|$21
ND949142-0010
0-RING
SN: A31001-UP-UP
1шт.
|$22
ND949142-0030
0-RING
SN: A31001-UP-UP
2шт.
20
ND146984-4750
GROMMET
SN: A31001-UP-UP
1шт.
21
ND246440-5200
WIRING HARNESS
SN: A31001-UP-UP
1шт.
22
ND949046-2150
BOLT
SN: A31001-UP-UP
2шт.
23
ND077500-3620
THERMOSTAT
SN: A31001-UP-UP
1шт.
24
ND063700-6580
SERVO MOTOR ASSEMBLY
SN: A31001-UP-UP
1шт.
25
ND705220-0500
HOSE, WATER
SN: A31001-UP-UP
3шт.
26
ND146625-2630
BUSHING
SN: A31001-UP-UP
2шт.
27
ND246690-2930
BUSHING
SN: A31001-UP-UP
1шт.
28
ND146625-5040
BUSHING
SN: A31001-UP-UP
2шт.
29
ND246690-2840
CLAMP
SN: A31001-UP-UP
3шт.
30
ND017231-1400
CLAMP
SN: A31001-UP-UP
1шт.
31
ND246690-6740
CLAMP
SN: A31001-UP-UP
3шт.
32
ND246690-5150
CLAMP
SN: A31001-UP-UP
3шт.
33
ND949351-0720
CLAMP
SN: A31001-UP-UP
6шт.
34
ND949001-1730
SCREW, TAPPING
SN: A31001-UP-UP
11шт.
35
ND949008-0780
SCREW, TAPPING
SN: A31001-UP-UP
3шт.
36
ND913700-3081
SCREW WITH WASHER
SN: A31001-UP-UP
3шт.
37
ND909300-5121
SCREW, TAPPING
SN: A31001-UP-UP
3шт.
38
ND909300-6141
SCREW, TAPPING
SN: A31001-UP-UP
12шт.
39
ND017773-0180
CLIP
SN: A31001-UP-UP
2шт.
40
ND017773-0140
CLIP
SN: A31001-UP-UP
1шт.
41
ND146642-7930
PLATE
SN: A31001-UP-UP
1шт.
42
ND700904-0050
SHEET
SN: A31001-UP-UP
1шт.
43
ND700901-0050
SHEET
SN: A31001-UP-UP
1шт.
44
ND116471-7200
BRACKET, CASE
SN: A31001-UP-UP
2шт.
45
ND116471-7210
BRACKET, CASE
SN: A31001-UP-UP
1шт.
N/I
ND116290-0322
FLANGE ASSEMBLY
SN: A31001-UP-UP
1шт.
N/I
ND914780-5161
BOLT WITH WASHER
SN: A31001-UP-UP
3шт.
N/I
ND245440-2191
CASE, COOLING UNIT
SN: A31001-UP-UP
1шт.
N/I
ND116471-6631
BRACKET, CASE
SN: A31001-UP-UP
1шт.
N/I
ND909300-4121
SCREW, TAPPING
SN: A31001-UP-UP
2шт.
N/I
ND915700-5121
BOLT WITH WASHER
SN: A31001-UP-UP
8шт.
N/I
ND145422-8431
SHEET, UNIT CASE
SN: A31001-UP-UP
1шт.
N/I
ND909300-6161
SCREW, TAPPING
SN: A31001-UP-UP
5шт.
N/I
ND909300-6121
SCREW, TAPPING
SN: A31001-UP-UP
10шт.
