|$4
TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)
SN: A36166-UP
-1шт.
|$5
TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)
SN: A36001-A36165
-1шт.
|$6
TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)
SN: A36166-UP
-1шт.
|$7
TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)
SN: A36001-A36165
-1шт.
|$8
VALVE ASS'Y,(SEE FIG. F4350-09A0)
SN: A36166-UP
-1шт.
|$9
VALVE ASS'Y,(SEE FIG. F4350-09A0)
SN: A36001-A36165
-1шт.
|$10
VALVE ASS'Y,(SEE FIG. F4350-09A1)
SN: A36166-UP
-1шт.
|$11
VALVE ASS'Y,(SEE FIG. F4350-09A1)
SN: A36001-A36165
-1шт.
|$12
714-07-26000
VALVE ASS'Y
SN: A36166-UP
1шт.
|$13
0
VALVE ASS'Y
SN: A36001-A36165
1шт.
1
17A-15-25131
BODY
SN: A36001-UP
1шт.
2
07042-20108
PLUG
SN: A36001-UP
2шт.
3
14X-15-15850
PLUG
SN: A36001-UP
1шт.
4
07002-03034
O-RING (KIT)
SN: A36001-UP
1шт.
5
714-07-25230
VALVE
SN: A36166-UP
1шт.
|$19
0
VALVE
SN: A36001-A36165
1шт.
6
426-15-15490
VALVE
SN: A36001-UP
1шт.
7
198-15-15770
SPRING, (L= 30.0)
SN: A36001-UP
1шт.
8
426-15-15480
VALVE
SN: A36001-UP
1шт.
9
198-15-15570
SHIM, 0.50MM
SN: A36001-UP
5шт.
10
426-15-16251
SPRING, (L=122.0)
SN: A36001-UP
1шт.
11
426-15-16261
SPRING, (L=108.0)
SN: A36001-UP
1шт.
12
426-15-15810
PLUG
SN: A36001-UP
1шт.
13
07002-03034
O-RING (KIT)
SN: A36001-UP
1шт.
14
12H-15-14130
SPOOL
SN: A36001-UP
1шт.
15
104-15-25490
VALVE
SN: A36001-UP
1шт.
16
125-15-15290
SPRING
SN: A36001-UP
1шт.
17
104-15-25480
VALVE
SN: A36001-UP
1шт.
18
14X-15-16210
SPRING
SN: A36001-UP
1шт.
19
12H-15-14140
GUIDE
SN: A36001-UP
1шт.
20
14X-15-15850
PLUG
SN: A36001-UP
2шт.
21
07002-03034
O-RING (KIT)
SN: A36001-UP
2шт.
|$36
714-07-05030
SERVICE KIT,T/M CONTROL VALVE
SN: A36001-UP
1шт.
|$37
714-07-05040
SERVICE KIT,T/M CONTROL VALVE (LOCK UP)
SN: A36001-UP
1шт.
