1
421-S62-4120
CONDENSER,(SEE FIG. C0110-11A0)
SN: 66001-UP
1шт.
2
423-07-31563
CONTROL PANEL A.,(SEE FIG. K0210-19A0)
SN: 85416-UP
1шт.
2
423-07-31562
CONTROL PANEL A.,(SEE FIG. K0210-19A0)
SN: 66001-85415
1шт.
3
423-S62-4171
HOSE,(SEE FIG. K0210-37A0)
SN: 66001-UP
1шт.
4
AN51439-D0051
O-RING,(SEE FIG. K0210-37A0)
SN: 66001-UP
2шт.
5
423-S62-4161
HOSE,(SEE FIG. K0210-37A0)
SN: 66001-UP
1шт.
6
AN51439-D0031
O-RING,(SEE FIG. K0210-37A0)
SN: 66001-UP
2шт.
7
423-S62-3370
PLATE,(SEE FIG. K0210-37A0)
SN: 66001-UP
1шт.
8
423-07-31340
HOSE,(SEE FIG. K0210-37A0)
SN: 66001-UP
1шт.
9
423-07-31350
HOSE,(SEE FIG. K0210-37A0)
SN: 66001-UP
1шт.
10
421-S62-4140
HOSE, 2800MM,(SEE FIG. K0711-03A0)
SN: 66001-UP
1шт.
11
AN51439-D0051
O-RING,(SEE FIG. K0711-03A0)
SN: 66001-UP
2шт.
12
421-S62-4150
HOSE,(SEE FIG. K0711-02A0)
SN: 66001-UP
1шт.
13
AN51439-D0041
O-RING,(SEE FIG. K0711-02A0)
SN: 66001-UP
2шт.
14
421-S62-4170
HOSE, 3590MM,(SEE FIG. K0711-03A0)
SN: 66001-UP
1шт.
15
AN51439-D0031
O-RING,(SEE FIG. K0711-03A0)
SN: 66001-UP
2шт.
16
421-S62-4160
HOSE,(SEE FIG. C0110-11A0)
SN: 66001-UP
1шт.
17
AN51439-D0031
O-RING,(SEE FIG. C0110-11A0)
SN: 66001-UP
2шт.
18
423-07-31571
RECEIVER DRYER,(SEE FIG. K0711-02A0)
SN: 66001-UP
1шт.
19
423-S62-4330
COMPRESSOR ASS'Y,(SEE FIG. K0711-01A0)
SN: 66001-UP
1шт.
20
AN51436-10320
CAP,(SEE FIG. K0210-15A0)
SN: 66001-UP
1шт.
