Запчасти Komatsu WA470-3 ТОПЛ. НАСОС(НАСОС)(/)(ВНУТР. ЧАСТИ) [ДВИГАТЕЛЬ]

1*

X16-0354001

INJECTION PUMP UNIT

Field_1: 70946-

1шт.

|$1

6152-72-1442

INJECTION PUMP A THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3K5B TO A4010-G3K5B

Field_1: 74801-

1шт.

|$2

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW

-1шт.

|$3

DK 106067-1520

PUMP ASS'Y THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3K5B AND

Field_1: 74801-

1шт.

1

DK 134063-3620

HOUSING

Field_1: 74801-

1шт.

2

DK 029040-6020

STUD

Field_1: 74801-

3шт.

3

DK 134311-0000

RING

Field_1: 74801-

1шт.

4

DK 134138-0000

STUD

Field_1: 74801-

12шт.

5

DK 016650-2230

BEARING

Field_1: 74801-

1шт.

6

DK 134303-0400

SHIM,0.60MM

Field_1: 74801-

-2шт.

|$10

DK 134303-0000

SHIM,1.20MM

Field_1: 74801-

-2шт.

|$11

DK 134303-0100

SHIM,1.50MM

Field_1: 74801-

-2шт.

|$12

DK 134303-0200

SHIM,1.80MM

Field_1: 74801-

-2шт.

|$13

DK 134303-0300

SHIM,2.00MM

Field_1: 74801-

-2шт.

7

DK 029010-6810

BOLT

Field_1: 74801-

4шт.

8

DK 134371-5700

CAMSHAFT

Field_1: 74801-

1шт.

9

DK 134306-0600

BEARING,CENTER

Field_1: 74801-

1шт.

10

DK 020106-2040

BOLT

Field_1: 74801-

2шт.

11

DK 016650-2230

BEARING

Field_1: 74801-

1шт.

12

DK 134316-1700

COVER

Field_1: 74801-

1шт.

13

DK 139629-0000

SEAL,OIL

Field_1: 74801-

1шт.

14

DK 134314-0000

SHIM,0.10MM

Field_1: 74801-

-2шт.

|$22

DK 134314-0100

SHIM,0.12MM

Field_1: 74801-

-2шт.

|$23

DK 134314-0200

SHIM,0.14MM

Field_1: 74801-

-2шт.

|$24

DK 134314-0300

SHIM,0.16MM

Field_1: 74801-

-2шт.

|$25

DK 134314-0400

SHIM,0.18MM

Field_1: 74801-

-2шт.

|$26

DK 134314-0500

SHIM,0.30MM

Field_1: 74801-

-2шт.

|$27

DK 134314-0600

SHIM,0.50MM

Field_1: 74801-

-2шт.

15

DK 029635-5010

O-RING

Field_1: 74801-

1шт.

16

DK 134563-0900

SLEEVE

Field_1: 74801-

1шт.

17

DK 134045-0100

PLUG

Field_1: 74801-

1шт.

18

DK 026524-2940

GASKET

Field_1: 74801-

1шт.

19

DK 139206-0400

NUT

Field_1: 74801-

3шт.

20

DK 131041-0800

GASKET

Field_1: 74801-

1шт.

21

DK 134047-0000

PLUG

Field_1: 74801-

6шт.

22

DK 025805-1910

KEY

Field_1: 74801-

1шт.

23

DK 134430-3520

BOLT,EYE

Field_1: 74801-

1шт.

24

DK 029341-4130

GASKET

Field_1: 74801-

2шт.

25

DK 029731-0120

BOLT,EYE

Field_1: 74801-

1шт.

26

DK 029341-0110

GASKET

Field_1: 74801-

2шт.

27

DK 029731-4680

BOLT

Field_1: 74801-

1шт.

28

DK 029341-4130

GASKET

Field_1: 74801-

2шт.

29

DK 131424-7520

VALVE,OVER FLOW

Field_1: 74801-

1шт.

30

DK 029341-4130

GASKET

Field_1: 74801-

2шт.
