Запчасти Komatsu WA470-3 ПЕРЕДНИЙ МОСТ 8 ПЕРЕДНИЙ МОСТ
№
Артикул
Название
Примечание
Количество
1B
421-22-23110
AXLE BRIDGE
EnglischBem: NOTE: Pos. (1B) included in Pos. (1) and (1A) Kit
1шт.
2
PLUG
EnglischBem: NOTE: Pos. (2) included in Pos. (1) and (1A) Kit
1шт.
3
07041-13612
PLUG
EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (1A) Kit
2шт.
4
O-RING
EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (1A) Kit
3шт.
5
BREATHER
EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (1A) Kit
1шт.
6
421-22-13230
HUB CARRIER
EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (1A) Kit
2шт.
7
PLUG
EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (1A) Kit
4шт.
8
O-RING
EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (1A) Kit
4шт.
9
O-RING
EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (1A) Kit
2шт.
10
01252-31040
SCREW
EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (1A) Kit
6шт.
11
SCREW
EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (1A) Kit
32шт.
12
PLAIN WASHER
EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (1A) Kit
32шт.
14
PIN
EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (1A) Kit
1шт.
15
O-RING
EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (1A) Kit
1шт.
16
SCREW
EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (1A) Kit
17шт.
17
SCREW
EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (1A) Kit
3шт.
18
PLAIN WASHER
EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (1A) Kit
20шт.
19
421-22-13290
COVER
EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (1A) Kit
1шт.
20
SCREW
EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (1A) Kit
1шт.
21
PLAIN WASHER
EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (1A) Kit
1шт.
