|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$7
714-07-20004
TORQFLOW ASS'Y
SN: (111869)-UP
1шт.
|$8
714-07-20002
TORQFLOW ASS'Y
SN: (111067)-(111868)
1шт.
|$9
0
TORQFLOW ASS'Y
SN: 70001-(111066)
1шт.
|$10
0
TORQFLOW ASS'Y
SN: (70001-(110482))
1шт.
|$11
714-07-20014
TORQFLOW ASS'Y,(WITH LOCK-UP)
SN: (111869)-UP
1шт.
|$12
714-07-20012
TORQFLOW ASS'Y,(WITH LOCK-UP)
SN: (111067)-(111868)
1шт.
|$13
0
TORQFLOW ASS'Y,(WITH LOCK-UP)
SN: 70001-(111066)
1шт.
|$14
0
TORQFLOW ASS'Y,(WITH LOCK-UP)
SN: (70001-(110482))
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
|$18
714-07-22033
CLUTCH ASS'Y,2ND AND 3RD
SN: (110483)-UP
1шт.
|$20
0
CLUTCH,2ND AND 3RD
SN: (70001-(110482))
1шт.
1
714-07-22134
SHAFT ASS'Y,2ND AND 3RD
SN: (110483)-UP
1шт.
1
714-07-22132
SHAFT AND CYLINDER A,2ND AND 3RD
SN: 70001-(110482)
1шт.
2
714-07-22661
PISTON,RANGE
SN: 70001-UP
2шт.
3
714-12-19711
DISC
SN: 70001-UP
17шт.
4
714-16-19730
PLATE,SEPARATE
SN: 70001-UP
19шт.
5
56D-15-12710
SPRING,WAVE
SN: (110483)-UP
17шт.
5
0
SPRING,WAVE
SN: 70001-(110482)
17шт.
6
714-12-12610
PLATE,END
SN: 70001-UP
2шт.
7
419-15-12140
RING,SNAP
SN: 70001-UP
2шт.
8
714-16-19220
RING,SEAL
SN: 70001-UP
2шт.
9
714-07-19320
RING,SEAL (K1)
SN: 70001-UP
2шт.
10
714-08-19570
WASHER,THRUST
SN: 70001-UP
4шт.
11
714-23-19430
BEARING,NEEDLE
SN: 70001-UP
3шт.
12
714-07-22462
GEAR,2ND
SN: 70001-UP
1шт.
13
714-07-22452
GEAR, 41 TEETH,3RD
SN: 70001-UP
1шт.
14
714-07-22532
GEAR, 53 TEETH,OUTPUT
SN: 70001-UP
1шт.
15
569-15-49530
RING,SNAP
SN: 70001-UP
1шт.
16
714-07-22542
GEAR, 29 TEETH,4TH
SN: 70001-UP
1шт.
17
714-07-29340
BEARING
SN: 70001-UP
1шт.
18
714-07-29350
BEARING
SN: 70001-UP
1шт.
19
419-15-12122
RING,SEAL (K1)
SN: 70001-UP
3шт.
