|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$7
714-07-20004
TORQFLOW ASS'Y
SN: (111869)-UP
1шт.
|$8
714-07-20002
TORQFLOW ASS'Y
SN: (111067)-(111868)
1шт.
|$9
0
TORQFLOW ASS'Y
SN: 70001-(111066)
1шт.
|$10
0
TORQFLOW ASS'Y
SN: (70001-(110482))
1шт.
|$11
714-07-20014
TORQFLOW ASS'Y,(WITH LOCK-UP)
SN: (111869)-UP
1шт.
|$12
714-07-20012
TORQFLOW ASS'Y,(WITH LOCK-UP)
SN: (111067)-(111868)
1шт.
|$13
0
TORQFLOW ASS'Y,(WITH LOCK-UP)
SN: 70001-(111066)
1шт.
|$14
0
TORQFLOW ASS'Y,(WITH LOCK-UP)
SN: (70001-(110482))
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
|$17
714-07-25020
VALVE ASS'Y,MAIN
SN: 80526-UP
1шт.
|$18
0
VALVE ASS'Y,MAIN
SN: (10139)-00080525
1шт.
|$19
0
VALVE ASS'Y,MAIN
SN: ((10139)-0070176)
1шт.
|$20
714-12-25001
VALVE ASS'Y,MAIN
SN: 70001-(10138)
1шт.
|$21
714-07-25030
VALVE ASS'Y,(WITH LOCK-UP)
SN: 80526-UP
1шт.
|$22
0
VALVE ASS'Y,(WITH LOCK UP)
SN: (10142)-00080525
1шт.
|$23
0
VALVE ASS'Y,(WITH LOCK-UP)
SN: ((10142)-0070176)
1шт.
|$24
714-12-25011
VALVE ASS'Y,(WITH LOCK-UP)
SN: 70001-(10141)
1шт.
|$25
714-07-26000
VALVE ASS'Y,MODULATION
SN: (10320)-UP
1шт.
|$26
0
VALVE ASS'Y,MODULATION
SN: 70001-(10319)
1шт.
1
17A-15-25131
BODY
SN: 70001-UP
1шт.
2
07042-20108
PLUG
SN: 70001-UP
2шт.
3
14X-15-15850
PLUG
SN: 70001-UP
1шт.
4
07002-03034
O-RING (K2)
SN: 70001-UP
1шт.
5
714-07-25230
VALVE
SN: (10320)-UP
1шт.
5
0
VALVE
SN: 70001-(10319)
1шт.
6
426-15-15490
VALVE
SN: 70001-UP
1шт.
7
198-15-15770
SPRING, (L= 30.0)
SN: 70001-UP
1шт.
8
426-15-15480
VALVE
SN: 70001-UP
1шт.
9
198-15-15570
SHIM, 0.50MM
SN: 70001-UP
5шт.
10
426-15-16251
SPRING, (L=122.0)
SN: 70001-UP
1шт.
11
426-15-16261
SPRING, (L=108.0)
SN: 70001-UP
1шт.
12
426-15-15810
PLUG
SN: 70001-UP
1шт.
13
07002-03034
O-RING (K2)
SN: 70001-UP
1шт.
14
12H-15-14130
SPOOL
SN: 70001-UP
1шт.
15
104-15-25490
VALVE
SN: 70001-UP
1шт.
16
125-15-15290
SPRING
SN: 70001-UP
1шт.
17
104-15-25480
VALVE
SN: 70001-UP
1шт.
18
14X-15-16210
SPRING
SN: 70001-UP
1шт.
19
12H-15-14140
GUIDE
SN: 70001-UP
1шт.
20
14X-15-15850
PLUG
SN: 70001-UP
2шт.
21
07002-03034
O-RING (K2)
SN: 70001-UP
2шт.
