1
CYLINDER (SEE FIG. T4150-01A0)
SN: A46001--UP
-1шт.
1
CYLINDER (SEE FIG. T4150-01A1)
SN: A46001--UP
-1шт.
2
421-70-11940
PIN, CYLINDER TO BELL CRANK
SN: A46001--UP
1шт.
3
01010-81630
BOLT
SN: A46001--UP
1шт.
4
421-70-11280
WASHER
SN: A46001--UP
1шт.
5
421-70-41410
SHIM, T=1.0
SN: A46001--UP
5шт.
6
421-70-21960
PIN, CYLINDER TO FRAME
SN: A46001--UP
1шт.
7
421-70-41410
SHIM, T=1.0
SN: A46001--UP
2шт.
8
01010-81630
BOLT
SN: A46001--UP
1шт.
9
421-70-11280
WASHER
SN: A46001--UP
1шт.
10
HOSE (SEE FIG. H4200-05A2 )
SN: A46001--UP
-1шт.
11
HOSE (SEE FIG. H4200-05A2 )
SN: A46001--UP
-1шт.
|$12
12
-1шт.
|$13
F1 - USED ON MACHINES EQUIPPED WITH STANDARD BOOM.
13
-1шт.
|$14
13
-1шт.
|$15
F2 - USED ON MACHINES EQUIPPED WITH HIGH LIFT BOOM.
14
-1шт.
