|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-07-20011
TORQFLOW ASS'Y,(WITH LOCK-UP)
SN: (110483)-UP
1шт.
|1
0
TORQFLOW ASS'Y,(WITH LOCK-UP)
SN: 80001-(110482)
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
|1
714-07-22050
CLUTCH ASS'Y,FOWARD AND REVERSE
SN: 80001-UP
1шт.
1
714-07-22151
SHAFT AND CYLINDER A,FOWARD AND REVERSE
SN: 80001-UP
1шт.
2
714-07-22652
PISTON,FOWARD AND REVERSE
SN: 80001-UP
2шт.
3
714-07-29720
DISC
SN: (10047)-UP
30шт.
|3
714-07-29710
DISC
SN: 80001-(10046)
30шт.
4
714-16-19730
PLATE,SEPARATE
SN: 80001-UP
32шт.
5
56D-15-12710
SPRING,WAVE
SN: (110483)-UP
30шт.
|5
0
SPRING,WAVE
SN: 80001-(110482)
30шт.
6
714-07-22720
PLATE
SN: 80001-UP
2шт.
7
714-07-22610
PLATE,END
SN: 80001-UP
2шт.
8
419-15-12140
RING,SNAP
SN: 80001-UP
2шт.
9
714-11-19230
RING,SEAL (K1)
SN: 80001-UP
2шт.
10
714-16-19210
RING,SEAL (K1)
SN: 80001-UP
2шт.
11
714-08-19570
WASHER,THRUST
SN: 80001-UP
4шт.
12
714-23-19430
BEARING,NEEDLE
SN: 80001-UP
3шт.
13
714-11-12720
SPACER
SN: 80001-UP
1шт.
14
714-07-22711
SPACER
SN: 80001-UP
1шт.
15
419-15-12591
BEARING
SN: 80001-UP
1шт.
16
714-07-29320
BEARING
SN: 80001-UP
1шт.
17
714-07-22422
GEAR,FOWARD
SN: 80001-UP
1шт.
18
714-07-22412
GEAR,REVERSE
SN: 80001-UP
1шт.
19
714-19-19210
RING,SEAL (K1)
SN: 80001-UP
5шт.
20
714-21-19810
RING,SEAL (K1)
SN: 80001-UP
2шт.
