Запчасти Komatsu WA500-1L КОЛЕНВАЛ БЛОК ЦИЛИНДРОВ

|$0

6211-31-1010

CRANKSHAFT ASSEMBLY

1шт.

1

NSS

CRANKSHAFT

1шт.

2

6210-31-1120

GEAR

1шт.

3

6150-31-1130

KEY

1шт.

4

6211-31-1420

PIN

1шт.

5

6211-31-8100

DAMPER ASSEMBLY

1шт.

6

6211-31-1440

PULLEY, NON-HARDENED

1шт.

|$7

6211-31-1410

PULLEY, HARDENED

1шт.

7

04020-01024

PIN, DOWEL

1шт.

8

01010-51025

BOLT

6шт.

8A

01643-31032

WASHER

6шт.

9

6210-81-8710

BOLT

6шт.

|$12

6210-21-8000

METAL BEARING ASSEMBLY (STANDARD)

1шт.

|$13

6210-21-8010

BEARING ASSEMBLY, MAIN (STANDARD)

7шт.

10

NSS

BEARING, UPPER

1шт.

11

NSS

BEARING, LOWER

1шт.

12

6210-21-8050

BEARING, THRUST (STANDARD)

1шт.

|$17

6210-29-8010

BEARING ASSEMBLY, MAIN (0.25mm UNDERSIZE)

7шт.

10

NSS

BEARING, UPPER

1шт.

11

NSS

BEARING, LOWER

1шт.

|$20

6210-28-8010

BEARING ASSEMBLY, MAIN (0.50mm UNDERSIZE)

7шт.

10

NSS

BEARING, UPPER

1шт.

11

NSS

BEARING, LOWER

1шт.

|$23

6210-27-8010

BEARING ASSEMBLY, MAIN (0.75mm UNDERSIZE)

7шт.

10

NSS

BEARING, UPPER

1шт.

11

NSS

BEARING, LOWER

1шт.

|$26

6210-26-8010

BEARING ASSEMBLY, MAIN (1.00mm UNDERSIZE)

7шт.

10

NSS

BEARING, UPPER

1шт.

11

NSS

BEARING, LOWER

1шт.

12

6210-29-8050

BEARING, THRUST (0.25mm OVERSIZE)

1шт.

|$30

6210-28-8050

BEARING, THRUST (0.50mm OVERSIZE)

1шт.

|$31

6210-27-8050

BEARING, THRUST (0.75mm OVERSIZE)

1шт.

|$32

6210-26-8050

BEARING, THRUST (1.00mm OVERSIZE)

1шт.
