|$0
TRANSMISSION ASSEMBLY(SEE FIG. F4320-01A0)
SN: A60001-UP-UP
1шт.
1
425-15-13212
GEAR
SN: A60001-UP-UP
1шт.
2
06002-32022
BEARING
SN: A60001-UP-UP
2шт.
3
425-15-11220
CAGE
SN: A60001-UP-UP
1шт.
4
07000-05280
O-RING - CAGE
SN: A60001-UP-UP
1шт.
5
01010-31235
BOLT
SN: A60001-UP-UP
4шт.
6
01643-31232
WASHER
SN: A60001-UP-UP
4шт.
7
425-15-13131
COVER
SN: A60001-UP-UP
1шт.
8
07000-05190
O-RING - COVER
SN: A60001-UP-UP
1шт.
9
425-15-05011
SHIM ASSEMBLY - TRANSFER GEAR
SN: A60001-UP-UP
1шт.
|$10
425-15-13580
SHIM - 0.006 IN. (0.15 MM)
SN: A60001-UP-UP
1шт.
|$11
425-15-13570
SHIM - 0.008 IN. (0.20 MM)
SN: A60001-UP-UP
1шт.
|$12
425-15-13560
SHIM - 0.012 IN. (0.30 MM)
SN: A60001-UP-UP
1шт.
|$13
425-15-13550
SHIM - 0.039 IN. (1.00 MM)
SN: A60001-UP-UP
1шт.
10
01010-81235
BOLT
SN: A60001-UP-UP
4шт.
11
01643-31232
WASHER
SN: A60001-UP-UP
4шт.
12
425-15-13430
COVER
SN: A60001-UP-UP
1шт.
13
07000-02145
O-RING - COVER
SN: A60001-UP-UP
1шт.
14
01010-81030
BOLT
SN: A60001-UP-UP
4шт.
15
01643-31032
WASHER
SN: A60001-UP-UP
4шт.
16
425-15-13222
GEAR
SN: A60001-UP-UP
1шт.
17
06003-30314
BEARING
SN: A60001-UP-UP
2шт.
18
425-15-13151
CAGE
SN: A60001-UP-UP
1шт.
19
07000-05270
O-RING - CAGE
SN: A60001-UP-UP
1шт.
20
425-15-05021
SHIM ASSEMBLY - TRANSFER GEAR
SN: A60001-UP-UP
1шт.
|$25
425-15-13640
SHIM - 0.006 IN. (0.15 MM)
SN: A60001-UP-UP
1шт.
|$26
425-15-13630
SHIM - 0.008 IN. (0.20 MM)
SN: A60001-UP-UP
1шт.
|$27
425-15-13620
SHIM - 0.012 IN. (0.30 MM)
SN: A60001-UP-UP
1шт.
|$28
425-15-13610
SHIM - 0.039 IN. (1.00 MM)
SN: A60001-UP-UP
1шт.
21
01010-81235
BOLT
SN: A60001-UP-UP
6шт.
22
01643-31232
WASHER
SN: A60001-UP-UP
6шт.
23
425-15-13190
PLATE
SN: A60001-UP-UP
1шт.
24
07000-72130
O-RING - PLATE
SN: A60001-UP-UP
1шт.
25
01010-81635
BOLT
SN: A60001-UP-UP
2шт.
26
01643-31645
WASHER
SN: A60001-UP-UP
2шт.
|$35
KIT, TRANSMISSION SERVICE (SEE FIG. F4900-01A0)
SN: A60001-UP-UP
1шт.
|$36
-1шт.
|$37
F1 - INCLUDED IN TRANSMISSION SERVICE KIT.
-1шт.
|$38
-1шт.
